The SKYDAS PREMIUM is a very high quality door set whose structure features extra rigidity and resistance. Following the tests carried out in the most famous IFT ROSENHEIM (Germany) testing laboratory, the SKYDAS PREMIUM door was certified to a high level - the 4th burglar security class WK4 (according to the ENV 1627). The doors can be bulletproof.
Structural features of resistance:
- The lock is protected by 2 plates of drilling-resistant manganese.
- The body of the main lock is installed in a protective steel box.
- High-security hinges.
- On the hinge side, there are 8 locking pins of Ø 16 mm.
- On the lock side, there are six locking points and an additional 2 pairs directed upwards and downwards.
- The door panel consists of a combined structure: grading, sheet and again grading.
- Double thermal insulation of the sheet: 3 cm layer of high density stone wool on both sides of the sheet.
- The entire ultra strong structure of the door is covered by finish boards whose colour and design can be customised.
- The lock pins are protected against damage by a sheet and 15 mm flexed profile of the door panel.
- The casing is fastened to the door opening by 17 shafts protected with 24 mm steel liners.
Product specification:
Rating of sound insulation - 45 dB Rw (C; Ctr)
Rating of thermal transmittance - 1,3 W/(m²*K)
Resistance to repeated opening and closing - 200 000 cycle
Identification of resistance to wind load - Class C3
Measurements of air permeability - Class 3
Identification of water tightness - Class 1A
Identification of mechanical strenght and rigidity - Class 4
Identification of fire resistance - EI30/EI45
|
|
Armored Entrance Door was ideated for the security and protection of houses, offices, shops, etc. Is certified Cl.4 Standard UNI ENV 1627/30:2000. The only weatherproof outdoor security door. Indeed, with its aluminium structure and stainless steel armour plating. Designed to meet the growing demand for security and reliability, as well as an eye to elegance and attention to detail, it is made to measure in range of wood, gothic, Ral and matt Ral colours and effects.
Technical Information:
Extruded aluminium profiles: Alloy 6060
Armour plating:frame/leaf with 4 mm thick AISI 304 stainless steel plate. Panel insulated with manganese steel plate 20/10
Accessories: 20/10 thick galvanised counterframe, burglar-proof aluminium hinges, reinforced aluminium corner cleats, stainless steel strikes, doble-bit key locks, lower and higher deviators, cylinder with Defender, aluminium draught excluder, aluminium burglar-proof brackets, seals in EPDM.
|
|
DOOR FRAME
- Sheet steel Door frame 20/10e
- Sheet Threshold steel 20/10e welded onto the door frame
- Resin Completion 100% polyester cooked with oven (RAL of the manufacturer)
- Seal 1 lip
- 4 hinge plates with weld steel board
CASEMENT
- Covering has
- Composed of an interior frame profile 15/10e and a steel tube
- A manganese armor plate
- Filling by rockwool thickness 40mm
- 4 weld steel hinge plates
- Interior Facing out of melamine or laminate imitation wood of 10mm thickness
- Facing external out of melamine or laminate imitation wood of 10mm thickness
- 5 fixed bolts antidégondage welded side pivot diam .16mm
- Joint peripheral pad isophonic
HARDWARE
- Crutch Unit doubles out of massive brass
- Lock multipoint A2P 3* with 3 keys protected profile. Chart of property personalized with identification number
|
|
