Gira now offers the Keyless In Keypad, Fingerprint and Transponder as a new function within the Gira door communication system. Integrated in the Gira door station, they are a convenient, secure alternative for keyless access to the house. The technology is based on electronic or biometric systems: The Gira Keyless In Keypad opens the door when a personal code is entered. The Gira Keyless In Transponder responds to the signal from a card or a transponder key. And the key can remain in your pocket: It automatically transmits the signal starting from 1.5 metres. Using the most modern high-frequency technology, the Gira Keyless In Fingerprint evaluates the structures of the deepest layers of skin on the finger. It's technology that provides a high level of security against manipulation.
|
|
- High quality image capture up to 500 dpi
- Self cleaning sensor
- Auto detection of finger
- Protected against ESD (electrostatic discharges):
- >16 kV of discharge in the air
- Drivers for Microsoft Windows 2000/XP
- Encrypted link to the PC
|
|
- CABAPROX has two different readers:
A . Fingerprint reader:
. Self cleaning sensor
. Operates with humid fingers
(choice of one or several fingerprints during recording)
. 1 relay output N/O & N/C contacts
. Tamper switch
. Input voltage: 12V AC/DC
. Optional: CABAPROX/W 26-bit wiegand output
B . Mifare® reader:
. High Impact reader head
. 42MM head, 25MM body
. Visual feedback
|
|
Surface mount stainless steel keypad
- Completely sealed (filled with epoxy)
- Remote controller mounted in a weather resistant plastic box
- Programming password protected
- Capacity 100 user code of 4 to 5 digits
- 1 form C output (optional: 2 to 3 relay outputs)
- Keypad Illumination duration programmable
- Audible feedback for operating and programming
- Request-to-exit input
- Timed output 1 to 99 seconds or latched
- All programming stored in non-volatile EEPROM memory
- Operating voltage: 12 to 24V AC and 12 to 48V DC
- Consumption (3 relay outputs activated and keypad illuminated):
. 12V AC: Standby 90mA
. 24V AC: Standby 46mA
. 12V DC: Standby 100mA
. 24V DC: Standby 55mA
. 48V DC: Standby 30mA
|
|
The V-Flex, installed next to a Wiegand based reader, adds dual factor authentication to an existing access control system.
Organizations with security systems that include keypads, barcode or proximity readers can now add the enhanced security offered by biometric technology without reissuing cards or replacing their existing infrastructure.
|
|
|
The fingertip reader can be used in two modes. In identification mode, the user is identified by fingerprint data only, whereas in verification mode a PIN code has to be entered as reference for the stored template to be compared with the actual fingerprint.
|
|
Extended function fingerprint scanner
Biometric access control for up to 99 users involving one-off production in accordance with project specifications
The fingerprint scanner increases the functional scope of (video) front-door stations by adding biometric access control. As a stand-alone unit, the compact fingerprint scanner can be used for opening doors or alternative applications involving up to 99 users. As a functional enhancement, it can be integrated into the flush-mounting front-door stations from the PUK and VPUK series as well as into display front-door stations. The fingerprint scanner can be integrated into one of the specified TCS front-door stations as a one-off product that is manufactured in accordance with the project specifications.
|
|
|
|
