For single family houses and apartments with a living area of max. 400 m².
• 1500 Watt max. - Biturbo
• 540 Airwatt max.
• LCD-Woking hour counter
• Quiet suction unit
• Tank of brushed stainless steel
• Connection up to 15 suction sockets
• Longest piping system 80 m
• Wall holder exempt from vibrations
• Two-stage, ball bearing mountec motor with automatic cut-out carbon
brushes and electronic soft start
• Suction line connection to the right and left
• Long service life cartridge filter
• Suction box in appliance
• Cyclone filter principe
• PE dust bag with clamping ring
• 45-litre dust cylinder
|
|
For guest houses, small hotels, offices and business buildings etc.
up to max. 800 m²
• 3400 Watt max. - Biturbo
• 1200 Airwatt max.
• LCD-Operation hour meter
• Tank of brushed stainless steel
• Connection up to 25 suction sockets
• Longest piping system - 120 m with 1 userr / 60 m with 2 users
• Wall holder exempt from vibrations
• Two-stage ball bearing mounted motors with automatic cut-off
carbon brushes and electronic soft start
• Long service life cartridge filter
• Cyclone filter principe
• PE dust bag with clamping ring
• Suction line connection to the right and left
• 45-litres dust cylinder
|
|
-High efficiency, thru-flow motor
-Ultra quiet operation
-Highly durable steel body with scratch-resistant silver metallic
powder coat paint
-Convenient clip on bucket with view window
-Self-cleaning filter or hygienic high-efficiency paper bag filter
-Compact size for flexible installation
|
|
Our NEW design is the ideal choice for a larger single-level, or multi-level home with remarkable performance and market leading product features.
-High efficiency, commercial grade by-pass motor for high performance with low energy consumption
-Self-cleaning filter made from Gore material
-Patented Serenity sound reduction system
-Highly durable steel body with scratch-resistant metallic alloy
powder coat paint
-Twist-lock dirt bucket with view window or optional see-thru bucket
infused with anti-microbial treatment
-Optional LCD system monitoring screen in blue backlit design
-Anti-vibration wall mounting system
|
|
For single and two familiy houses up to an living area of max. 400 m²
• 1700 Watt max. Biturbo
• 500 Airwatt max.
• Connection for electrical tools
• Tank of stainless steel
• Connection up to 15 suction sockets
• Longest piping system 60 m
• Mobile unit
|
|
Breathe a breath of fresh air into your home. Thanks to TUBÒ, a system that:
- cleans dust with a flexible hose;
- pipes it to the central unit, where it’s filtered;
- pipes the big dust particles into the dust bag;
- filters and capture airborne dust in the dust filter cartridge;
- expels the micro dust outdoors through the air expulsion line
The TUBÒ system is so simple, fast and safe that can be used by anyone in the family.
Bravo, the built-in vacuum cleaner
Where space is an issue, there’s BRAVO
Aertecnica has built all the advantages of the vacuum system into a small and powerful product; silent, easy to install and use.
The machine is installed in a hole in the perimeter wall: the ideal solution for bed sits, shops, small offices, bars, garages, and all those situations where space is an issue.
|
|
Breathe a breath of fresh air into your home. Thanks to TUBÒ, a system that:
- cleans dust with a flexible hose;
- pipes it to the central unit, where it’s filtered;
- pipes the big dust particles into the dust bag;
- filters and capture airborne dust in the dust filter cartridge;
- expels the micro dust outdoors through the air expulsion line
The TUBÒ system is so simple, fast and safe that can be used by anyone in the family.
|
|
Breathe a breath of fresh air into your home. Thanks to TUBÒ, a system that:
- cleans dust with a flexible hose;
- pipes it to the central unit, where it’s filtered;
- pipes the big dust particles into the dust bag;
- filters and capture airborne dust in the dust filter cartridge;
- expels the micro dust outdoors through the air expulsion line
The TUBÒ system is so simple, fast and safe that can be used by anyone in the family.
|
|
|
|
|
|
Breathe a breath of fresh air into your home. Thanks to TUBÒ, a system that:
- cleans dust with a flexible hose;
- pipes it to the central unit, where it’s filtered;
- pipes the big dust particles into the dust bag;
- filters and capture airborne dust in the dust filter cartridge;
- expels the micro dust outdoors through the air expulsion line
The TUBÒ system is so simple, fast and safe that can be used by anyone in the family.
QB, the new built-in central unit of the TUBÒ system.
Innovating, developing products suitable for every context.
This is why Aertecnica has chosen a new direction, with the first built-in central unit, for external or internal environments.
Designed to disappear, it is available in a wide range of colours, the epitome of space and silence.
For residential buildings and designed to be totally hidden, QB meets the requirements of modern civil engineering: it’s easy to install also in environments where it would be difficult to use a normal central vacuum unit for lack of space or aesthetic reasons.
QB is the first built-in central vacuum unit.
|
|
Breathe a breath of fresh air into your home. Thanks to TUBÒ, a system that:
- cleans dust with a flexible hose;
- pipes it to the central unit, where it’s filtered;
- pipes the big dust particles into the dust bag;
- filters and capture airborne dust in the dust filter cartridge;
- expels the micro dust outdoors through the air expulsion line
The TUBÒ system is so simple, fast and safe that can be used by anyone in the family.
|
|
The Kompatta three-phase line, called “KT”, was designed and built to meet the requirements of the tertiary/professional sector.
Made to the high Aertecnica standards, the new KT range has been realised with a “PLUG & PLAY” concept, to offer our installer total reliability, and in particular fast installation, so the product can be put into service as quickly as possible, while also reducing the overall dimensions of the installation.
The three-phase Kompatta, is designed as a monobloc structure, divided into three sections:
- Top Section: motor compartment.
- Central Section: dust-catcher filter.
- Bottom Section: cyclone and cleaned material storage.
The Kompatta KT range has been designed to offer the maximum versatility and meet the requests of a market that is constantly evolving and all the more demanding.
|
|
|
|
|
|
All the models of the THREE-PHASE PERFETTO line, modules and separators, are fitted with electronic systems to improve performance, optimize energy consumption and make them easier to use, letting you check the functions of the system at a glance.
VACUUM MODULE DISPLAY
The electronic display lets you set and show all the operating parameters of the vacuum module.
Perfetto line: the vacuum modules
The latest technology is also used in the vacuum modules: soundproofed and supplied with a display, and managed by an intelligent electronic board that controls the state of the machine.
Furthermore, the vacuum modules with automatic/electronic adjustment use the SOFT START system, which guarantees lower power consumption.
The state of the machine is displayed both on the display of the module, and on the CONTROL DISPLAY, installed in the most practical place (reception, floors, etc.).
The display on the vacuum module shows:
- the amperes absorbed by the motor
- the maximum time the vacuum module is used continuously
- the hours of work of the vacuum module
- the temperature in the motor chamber
- the working vacuum in mm H2O
Unlike normal central vacuum systems, the new modules can be connected in parallel.
|
|
|
|
|
|
The targata innovation Aertecnica offers before centers them vacuum cleaner to proceeds completely, from today with the possibility to be installed also to wall, for the cetralized systems vacuum cleaner: brevettata*, silent, beautiful, no I block, works them and resistant.
The ideal solution for atmospheres of pregio that they watch to the functionality and the esthetic one.
It is modern, it guarantees functionality and innovation with detail attention to the esthetic one and the design. The best choice for the residential building.
QB represents a perfect synthesis between technological innovation and design: the case to proceeds in galvanized steel is equipped of connections for the connection to the pipages and predisposed for the connection electrical worker. It centers them QB it is coibentata thermally and soundproofed and it can be installed in all and the two cases, or that to proceeds that to wall.
The great added value of centers them QB* is given from the careful planning that, in spite of the remarkable transformation of blocks, has conserved intact the prestazionali characteristics of centers them aspirant.
License Aertecnica (patent pending n° M020074000077)
New centers them revolutionary aspirant
Maximum power aspirant
Cyclonic space of collection powders and ecological storage powders in cardboard, extractable.
Absolute silenziosità (dB 58)
Simplified maintenance
Maximum degree of protector (IP55) **
I block reduced
Possibility to be installed or to proceeds that to wall
|
|
Good things come in small packages. No saying could be more fitting to this DRAINVAC central vacuum series. This compact application is perfectly suited to condos, apartments, RVs, and regular homes. But don’t let its size fool you. This is a powerful little machine!
Advantages:
- Compact
- Suction that is 15% stronger than competition’s
- Antibacterial filter and large bag makes it easier to collect dust and improve air quality
- Large-capacity bag means it only needs to be replaced once per year
- As quiet as a normal conversation
- Different models available for different homes and different budgets
|
|
This patented DRAINVAC central vacuum does it all! It cleans both dry and liquid substances, and then it drains them automatically into your piping system. All you need to do is plug the hose into one of your inlets, and start cleaning. When you’re done, put the hose away.
That’s how easy it is to clean with the Automatic Series. Perfect for any house.
Advantages:
- Wet and dry cleaning
- Ideal for carpets, upholstered furniture, mattresses, car interiors, and more
- No post-cleaning maintenance required
- No need to wash the tank
- Superior suction
|
|
Want something that lasts? This DRAINVAC application won’t let you down. Made with sturdy materials, this central vacuum is resistant to both dry and liquid substances. Put away the mop and broom. This series is ideal for any house.
Advantages:
- Strong suction guaranteed
- Has rustproof polyethylene interior
- Corrosion-free
- No bag or filter required on certain units
|
|
The continuous growth of SACH has meant an adjustment to the needs of the market. Typhoon Evo by SACH is technically the most developed central vacuum unit in the market. Technology, design, sturdiness, power, silence; a line of central vacuum units made in ABS resin with ergonomic shapes.
Its main features are: triple filtering system (cyclone, anti-bacteria, HEPA), progressive start-up, new design silencer, high speed bypass motors with conical stages, dirt container with a polycarbonate fill indicator and thermal reset protection.
The new Typhoon Evo central units incorporate a LED or LCD control panel on the top, which allows controlling the unit at all times. Thanks to the electronic management of the motor, the LCD series incorporates a deluxe hose with an on/off switch that allows regulating the suction flow from the handle itself, but adapting to the needs of the most demanding clients.
|
|
A New And Revolutionary Concept In Central Vacuum Systems For Apartments.
New Concept is a modern high-performance central unit that is designed for its perfect integration in apartments. Its small design allows simple installation in the home, since it can be placed in any cupboard in the kitchen, the office, the laundry room.
Its low level of noise makes it the perfect choice to clean in small spaces, since it does not disturb any domestic activity that may be carried out during its use.
New Concept is a cutting-edge central vacuum unit and its features make it the ideal choice for comfortable and effective cleaning.
|
|
The continuous growth of SACH has meant an adjustment to the needs of the market. Typhoon Evo by SACH is technically the most developed central vacuum unit in the market. Technology, design, sturdiness, power, silence; a line of central vacuum units made in ABS resin with ergonomic shapes.
Its main features are: triple filtering system (cyclone, anti-bacteria, HEPA), progressive start-up, new design silencer, high speed bypass motors with conical stages, dirt container with a polycarbonate fill indicator and thermal reset protection.
The new Typhoon Evo central units incorporate a LED or LCD control panel on the top, which allows controlling the unit at all times. Thanks to the electronic management of the motor, the LCD series incorporates a deluxe hose with an on/off switch that allows regulating the suction flow from the handle itself, but adapting to the needs of the most demanding clients.
|
|
-Hush 2-stage motor
-5 gallon capacity
-Covers 3,000 sq. ft.
|
|
This multifunctional system picks up dry substances. It’s powerful, versatile, and ideal for environments that produce a lot of dust.
Advantages:
- Up to 5080mm water lift (H2O) for superior suction
- Extremely good for picking up fine dust particles
- Can cover large surface areas
- Many filtration methods available
- Large filtration capacity can recuperate up to 68 litres of dry matter
|
|
|
Because it can pick up dry and liquid substances, this convenient all-in-one DRAINVAC system simply pays for itself! This series boasts leading technology as the world's first central vacuum with an integrated automatic drain system.
|
|
The Tertiary Sector is the range of central units and motor groups that SACH provides to reliably cover any type of services installation: hotels, hospitals, old people's homes, office buildings, shopping centres, clinics, museums, large mansions, cinemas, theatres, etc.
There are different types of optimised configurations in order to provide the most adequate service for each project. The number of power units and the size of the dust separator will vary according to the square metres of surface to be covered and the number of simultaneous users desireds.
|
|
Area of application: Einfamielienhaus, and/or Doppelhaus
max. overall length of the Saugrohrleitungen: 30 - 35 meters
max. suction power (negative pressure): 3482 mmWS
max. air Watts: 448
max. air run: 44.70 Liter/s
max. amperage: 7 ampere
max. capacity: 1566 Watts
Control voltage: 24 V
Turbine stages: 3
Noise level: 64 dbA
Engine: AMETEK/LAMB - tangential, model No. 117123
Filter system: HEPA conformal teflon filter continuous filter, maintenance-free
Indicated altitude: 103 cm
Diameter: 30 cm
Wall assembly: Supporting device - enclosed
Weight: 14 kg
Staubbehälter: 19 L
Encasing material: Steel
|
|
Area of application: Single family house, and/or Doppelhaus small hotel and local plants
max. overall length of the Saugrohrleitungen: 80-90 meters
max. suction power (negative pressure): 3698 mmWS
max. air Watts: 521
max. air run: 48.30 Liter/s
max. amperage: 7.4 ampere
max. capacity: 1619 Watts
Control voltage: 24 V
Turbine stages: 3
Noise level: 63 dbA
Engine: AMETEK/LAMB - tangential, model No. 117502
Filter system: HEPA conformal teflon filter continuous filter, maintenance-free
Indicated altitude: 104 cm
Diameter: 36 cm
Wall assembly: Supporting device - enclosed
Weight: 17 kg
Staubbehälter: 30 L
Encasing material: Steel
|
|
|
|
