- Polycarbonate casing
- Surface mount
- 26, 30 or 44-bits wiegand output selectable
- Completely sealed filed with epoxy
- Reading range 15cm (with CPE card)
- LED and built-in buzzer
- Input voltage: 12V DC
- Consumption: 100mA |
|
- Simplifies the installation of dual-locking doors
(2 mag locks or mag lock and door strike)
- 2 form C relay lock outputs
- 2 relay status LEDs
- Connects directly to the CT-V900-A lock
output terminals
- Current consumption: 100mA
- Lock outputs: 2 form C relays rated at 5A/12Vdc,
N.C./N.O |
|
- Connects directly onto the CA-A480-A elevator controller
- One-card swipe, one-floor operation
- Eliminate elevator cab tailgating.
Each rider must present their card to select a floor button
- 16 floor-selection inputs and LED indicators
- Records Valid and Invalid floor selections
- Power input: 5Vdc
- Current consumption: 28mA (typical), 108mA (max)
- Inputs: 16 floor selection inputs
- Select activation LED: Yes (16 LEDs)
- DC input activation: 15Vdc (minimum), 16.5Vdc (max)
- Connection method: 14-way Flat Cable to CA-A480-A |
|
- 16 on-board floor control relays
- Fire control input
- Control up to 64 floors and 2 elevator cabs
- Destination reporting (requires CA-A482-P
Destination Reporting Module)
- Connects directly to the RS-485 E-BUS
- Backup battery with selectable battery charge current
- Individual schedules per floor
with on-board 12Vdc power supply
- Fully supervised (tamper, low battery and AC failure)
with comprehensive LED display
- Fire alarm: 1
- Tamper: 1
- Relay outputs: 16 form C relays rated
at 20A/16Vdc, N.C./N.O |
|
- Stainless steel casing
- Surface mount
- 26, 30 or 44-bits wiegand output selectable
- Completely sealed filed with epoxy
- Reading range 10cm (with CPE card)
- LED and built-in buzzer
- Input voltage: 12V DC
- Consumption: 100mA |
|
- Polycarbonate casing
- Surface mount
- 26, 30 or 44-bits wiegand output selectable
- Completely sealed filed with epoxy
- Reading range 60cm with CPE card and 40CM with PPC KEY FOB
- LED and built-in buzzer
- Input voltage: 12V DC
- Consumption: 350mA to 450mA
* The reading Performances were taken in an environment free
of any electromagnetic disturbances |
|
- 4 channel remote transmitter
- 433 MHz frequency
- Rolling Code
- 6 V battery (type CR 2025) |
|
- Material: Cast aluminium (body and digit keys)
- Completely sealed (filled with epoxy)
- Non-volatile storage memory E2PROM
- Built-in buzzer
- Code length of 4, 5 or 6 digits
- 26-bit Wiegand output (Clock, Data 0 and Data 1)
- Input voltage: 12V DC
- Consumption: 100mA |
|
- 26, 30 or 44-bit wiegand output selectable with jumper
- Self cleaning sensor area (auto cleaning)
- 3 LED's for indication of the sweeping direction
- Based on the thermal-electric CMOS sensor from Atmel
- Resistant to abrasion: > 1 million finger sweeps
- Resolution: 500 dpi (FBI-Standard)
- 256 greyscales and 320 x 440 pixels
- ESD: > 16 kV air discharge
- Encrypted communication link with the PC
- Support of a dynamic firmware-upload
respectively firmware-update
- False-Acceptance-Rate: 1,5 * 10-5
- False-Rejection-Rate: 2 * 10-2
- Matches per Second: 3000 matches
- 1 Output N/O & N/C contact
- Tamper switch
- Input voltage: 12V AC/DC
Specific features for the CABAPROX
- Fingerprint reader + Mifare® Proximity reader
- Template stored on the badge
- Consumption: 450mA |
|
- 26, 30 or 44-bit wiegand output selectable with jumper
- Self cleaning sensor area (auto cleaning)
- 3 LED's for indication of the sweeping direction
- Based on the thermal-electric CMOS sensor from Atmel
- Resistant to abrasion: > 1 million finger sweeps
- Resolution: 500 dpi (FBI-Standard)
- 256 greyscales and 320 x 440 pixels
- ESD: > 16 kV air discharge
- Encrypted communication link with the PC
- Support of a dynamic firmware-upload respectively
firmware-update
- False-Acceptance-Rate: 1,5 * 10-5
- False-Rejection-Rate: 2 * 10-2
- Matches per Second: 3000 matches
- 1 Output N/O & N/C contact
- Tamper switch
- Input voltage: 12V AC/DC
Specific features for the DGID/W
- Templates memorized on the device database
- Software included
- Stores up to 1000 Fingerprints in the local database
- Consumption: 150mA |
|
- Converts TCP/IP protocol to RS-232
- Simple programming & setup
- Static IP Addressing
- RJ-45 connection to the LAN
- Comprehensive LED status indicators
- RS-232 serial connector supplied
- Uses common communication software for setup
- Supports TCP/IP, HTTP, ICMP and ARP protocols
- Ethernet Compatibility: Version 2.0/IEEE 802.3
- 10 MBPS - Half Duplex
- 9600, 19200 and 38400 serial baud rates
- Serial Line format: 8 data bits, 1 Stop bit, No Parity
- PCB Dimensions: 10cm x 6.4cm (4in x 2.5in) |
|
- RS-485 "star" configuration is a snap
- Provides a higher network isolation from noise
- Saves on wiring costs
- LED indicators for power, network and port activity
- Create 4 independent RS-485 networks
from 1 RS-485 network
- Connects to the CT-V900-A RS-485 and E-Bus
communication ports
- Connect controllers or expansion modules up to 1220m
(4000ft) from the hub
- Power Requirements: 10 to 14.6Vdc
- Current consumption: 190 mA typical
- Operating temp: -10°C to 55°C (14°F to 131°F) |
|
- 128 readers (doors)
- 2 944 Cardholder files
- 17 664 badges
- 30 time zones
- 16,000 events stored in a memory
- 8 different technologies:
. Dallas type (see page 33)
. Proximity (see page 34)
. Infrared (see page 34)
. RF receiver (see page 38)
. Keypad (see page 42)
. Magnetic (see page 43
. Long range reader (see page 37)
. Fingerprint reader (see page 39)
- Up to 10 operators
- All data stored on the controller
- Multi-sites controlled from one host management
- Downgraded modes
- Thermal printer output
- Free access
- PC requirements:
. Processor: 500 MHz
. Memory: 128 Mb
. Hard drive space: 50 Mb
. Compatible with Win 98/XP/2000
- Input voltage: 12V AC/DC
- Consumption: 200mA |
|
LT20PB/IP
- Same as LT20AC but with TCP/IP interface
- 128 doors
- 2500 cardholders and 3000 assets
- 8 inputs and 4 relay outputs
- All doors are opened in case of emergency
- Client server architecture
- 500 events
- Real time calendar and clock
- Holiday's functions
- Interlock and airlock feature
- Non-volatile memory
- Utilises low costs CAT5 UTP or Belden cabling
- 8 inputs/4 relay outputs
- Access control and time management reporting
- ODBC compliant database
- Plug & Play installation compatible
- RS232, USB & TCP/IP connectivity to associate
distributed intelligence cardholders
- Door alarm monitoring
- Mains and battery failure low messages (LT20AC
version only)
- Input voltage : 12V DC
- Consumption : 560 mA |
|
- Control 2 doors (Reader In / REX Out)
or 1 Door (Reader In / Reader Out)
- Add up to 6 more doors to the CT-V900-A
using the CA-A470-A expansion module
- 10,920 on-board card database
- 256 Schedules
- 256 Access Levels
- 2048 Event Buffer
- 16 on-board inputs (*using ATZ 2R/3R)
- 2 on-board 12 Vdc or 24 Vdc field-selectable lock outputs
- 2 on-board Form C dry contact relay outputs (N/O - N/C)
- Fully distributed database architecture
(access decisions made locally)
- Flash firmware - Upload firmware via the computer
- E-Bus technology add-on hardware modules can
be up to 1220m (4000ft) away from the CT-V900-A
- 2.5A switching power supply
- Supports common Wiegand, Track 2 ABA (mag stripe)
and BCD (keypad) formats
- Easy maintenance with snap-off terminal blocks
- Battery backup functionality (2 x 12V 7AH gel-type batteries)
- Lithium battery protection in case of complete power failure
Communication :
- Plug and play technology
- RS-485 E-Bus for expansion modules
- Connect modules up to 1220m (4000ft) away from the controller
- RS-232/485 port enabling communication with the software
Elevator Control :
- Controlled elevators: 2 cars/cabs with 64 floors per car/cab
- Schedules per floor: Yes
- Floor groups: 128
- Requirements: Standard, Professional
or Enterprise edition software |
|
- 2 readers and/or keypads
- 2 lock outputs
- 4 Inputs (door contacts and REX devices)
- Adds 2 doors to the CT-V900-A
- Up to three CA-A470-A modules per CT-V900-A
- 6 reader outputs (Red/Green LEDs, Buzzer)
- E-Bus connectivity to the CT-V900-A up to 1220m (4000ft)
- Supports Wiegand, Magnetic Stripe Track II ABA,
BCD keypad formats
- Comprehensive LED status indicators
- Reader inputs: 2
- Keypad inputs: 2
- Multi-purpose inputs: 4
- Lock outputs: 2 form C relays rated at 5A/30Vdc, N.C./N.O
- Reader Outputs: Six 25mA transistor outputs |
|
- Converts RS-485 protocol to RS-232 / USB protocol
- Allows a total of up to 1220m (4000 feet) of RS-485
- Utilizes UTP cable (Cat 5)
- Transmit, Receive and Power status LEDs
- Power Requirements: 12Vdc
- Current consumption: 100mA max
- Operating temp: -10°C to 55°C (14°F to 131°F) |
|
- Adds 7 form C relay outputs (N/O N/C)
to the CT-V900-A controller
- Maximum 2 CA-A460-P modules per CT-V900-A controller
- Connects directly to the CT-V900-A expansion bus
- Power input: 12Vdc
- Current consumption: 50mA (typical), 400mA (maximum)
- Outputs: 7 form C relays rated at 5A/28Vdc, N.C./N.O |
|
- Adjustable backlight and contrast
- Supports multiple language displays
- Display unit for time and attendance
- 32-character LCD display (2 lines - 16 characters each)
- Connect up to 8 CK-TRAK-L to the CT-V900-A controller E-Bus
- Can be used with Anti-passback applications
to display card locations
- Power input: 9 to 16Vdc
- Current consumption: 80mA maximum
- LCD: Super Twisted Nematic display (STN)
- Wide viewing angle |
|
| GE's Diamond II security system platform technology offers integrated security management for access control, alarm monitoring, and video integration with the flexibility to integrate across multiple geographic markets. Whether you are an up and coming organization requiring general access control, a multi-national corporation requiring sophisticated access control for global enterprise applications, or a government facility requiring SCIF area control, our technology is designed to meet your organization's specific needs. |
|
Onity HT22i - System Features
The Onity HT22i system gives you total control of your property in a PC-free and PMS compatible solution. The compact design requires little front desk space. 80
• Fully featured stand-alone system, no PC required
• Specially designed for properties with up to 500 rooms
• Insertion or Motorized Encoding Technology
• Direct interface with any PMS system
• Easy-to-read wide screen display with user-friendly menu
• Up to 8 check-in stations can be linked in a multi-front-desk configuration with up to 100 operators
• Internal modem: Remote update of the software or the locking plan and remote reporting capabilities.
• Exclusive OmniMaster Masterkeying System: Up to 100 different types of master cards assigned to 250 individual users.
• Provides staff shift timetables
• Works with a wide variety of Onity stand-alone locks
• Able to control full range of off-line and on-line Onity options
• Upgradeable to more complex Onity systems
• Worry-Free Guarantee Worldwide
|
|
The S-600 system is designed as a modular structure: after purchasing its basic package it´s possible, when necessary, to expand the system along with scaling up the supervised area and scope of its tasks and functions.
The S-600 system is constructed as a network of controllers connected to a dedicated computer. The controllers manage the operating devices %u2014 locks and turnstiles. The maximal number of controllers in the system is 64. The S-600 system supports HID or EM-Marin proximity cards used as electronic passes. The maximal number of cards is 64,000.
The system can operate two types of controllers: lock controllers and turnstile controllers.
|
|
|
|
