The EKCO electric central heating flow boilers are designed for wet central heating installations. They can either operate as an independent source of heat or cooperate with other boilers. The application of the proper control system ensures high heat comfort, nearly maintenance free work as well as the possibility of individual setting adjustment. The quick system reaction to the changes of temperature together with the automatic 6-stage power modulation ensures the maximum efficiency in the power consumption.
The EKCO electric central heating flow boilers are perfectly suitable for buildings where there is no possibility of gas system or it will be introduced in the future. The installation of the EKCO boliers entailes very low investement costs, electric mains are the only requirement. The boilers are very frequently installed in places used seasonally such as summer houses. They are often placed in objects in which there is limited availability to build a chimney.
The EKCO boilers are ideal for supporting the heating of places in which the main source of heat is solid fuel or wood-open fireplace. In this case the high thermal comfort is kept together with low cost and confidence that the anti-freezing temperature in the house will be sustained during the owner's absence.
The EKCO boilers can also parallelly cooperate with another gas or oil boiler. Such a system permits the boiler to work during a cheap, off-peak tariff which guarantees a significant cost cuts.
For more information please, visit our webside at: http://www.kospel.pl/index_en.php
|
|
|
Is always a pleasure living in a warm and comfortable house. For this reason day by day Ferroli's engineering research the best solution, mixing innovating technology, experience and design, they provide you with high security, efficiency and versatile for all their products.
|
|
|
|
|
|
Precision (+/- 0.5C) and high performance
¬ It includes different grades of power which offer a longer useful life and operation without breaks
¬ Electric control system for all power grades
¬ Integrated electric control panel
¬ Standard equipment on those which are optional for other manufacturers
¬ Easier installation
¬ Suitable for temperatures up to 100ºC
¬ Electric control system for all power grades
¬ 45 – 600 kw
¬ For more power and specific projects, please contact us
¬ 38,700 - 516,000 kcal/h
¬ ¬1.0 – 6.0 kg/cm2
¬ 400V,III,50/60 Hz (Optional:230V,III)
Resistance:
¬ Shielded with a copper tube and powdered magnesium
Integrated electric control panel
¬ Precision (+/- 0.5C) and high performance
¬ Fractional power. Three stages in all grades
¬ All stages with their own differential switch, automatic switch and contactor.
¬ Totally wired control panel
¬ Linear sequence grade control
¬ Forced air circulation within the control panel
Copper sealing protected with methacrylate
Circuit cut-out breaker in main plug ( depending on power)
Electric control system and reading of grades
Precision of +/- 0,5ºC in water outlet
¬ Temperature cut-out
¬ Pressure relief valve
¬ Pressure safety cut-out in case of lack of water
¬ General status signal unit (On-Off)
¬ Security status
¬ Activated grades
¬ Number of activated stages
Polyethylene foam
Supply meter (kw/h)
Outlet valve
|
|
|
|
|
|
steam up to 180 ºc
¬ Boilers designed to offer maximum performance, precision (+/- 0.5ºC) and working life.
¬ Different grades of power and electric control system for all power grades.
¬ Pressure electronic control.
¬ Integrated electric control.
¬ Dry steam for higher efficiency.
¬ Easier installation.
¬ Suitable for temperatures up to 180ºC.
Power:
¬ 3 %u2013 750 kw.
¬ For more power and specific projects, please contact us.
Capacity:
¬ 2,580 %u2013 645,000 kcal/h.
Working pressure:
¬ Mod.N-2 a N-12: atmospheric pressure.
¬ Mod.N-3/I y post.:6 kg/cm2.
Voltage:
¬ 400V,III,50/60 Hz 230 VII.
Resistance:
¬ Made of Incoloy with insulation of powdered magnesium.
Integrated Electric Panel:
¬ Fractional power: Three stages in all grades from 30kw on.
¬ Copper sealing protection with methacrylate.
¬ Circuit cut-out breaker in main plug (depending on power).
Transmission:
¬ Top connection..
¬ Circuit cut-out breaker in main plug (depending on power).
Pressure control:
¬ Pressure safety cut-out and data reading.
Level control:
¬ Electric control of maximum, minimum and security levels.
¬ Boiling stabilizer.
Security systems:
¬ Pressure relief valve.
¬ Electronic controls.
¬ Pressure safety cut-out.
Pilot lights:
¬ General status signal unit (On-Off).
¬ Activated grades.
¬ Security status in all grades.
¬ Number of activated stages.
Water supply:
¬ Electric pump with electric valve and filter (models NGP).
¬ Manually controlled valve.
|
|
|
|
|
|
Boilers with no cracking effect which offer a longer useful life.
¬ Maximum temperature precision:+/- 0.5ºC.
¬ Power gradation with self electric control system for all power grades.
¬ Integrated electric control.
¬ Easier installation.
¬ Suitable for temperatures up to 300ºC.
Power:
¬ 30–500 kw.
¬ For more power and specific projects, please contact us.
Capacity:
¬ 25,800–430,000 kcal/h.
Work pressure:
¬ atmospheric.
Voltage:
¬ 400V,III,50/60 Hz.
Resistance:
¬ Inox 321.
¬ With insulation of powdered magnesium.
Integrated Electric Panel:
¬ Fractional power: Three stages in all grades.
¬ All stages with their own differential switch, automatic switch and contactor.
¬ Linear sequence grade control.
¬ Forced air circulation within the control panel.
¬ Copper sealing protected with methacrylate.
¬ Circuit cut-out breaker in main plug.
Temperature control:
¬ Electronic thermometer/thermostat with data reading.
Security systems:
¬ Pressure safety valve.
¬ Temperature cut-out.
Optical signalling:
¬ General status signal unit (On-Off).
¬ Activated grades.
¬ Security status in all grades.
¬ Number of activated stages.
Tank:
¬ In steel/carbon.
¬ Insulation of kaolin wool.
Accessories:
¬ Supply meter (kw/h).
Outside finish:
¬ Assembled on a tubular chassis.
¬ Covered with a sheet of wood and paint furnace finished Epoxi.
|
|
Sussman SVS Electric Boilers are safe, versatile easy to-use heat sources for low or high pressure steam. Applications include steam for:
-CHEMICAL TANKS
-REACTORS, DISTILLATIONS & AUTOCLAVES
-DYESTUFFS
-FOOD PROCESSING
-JACKETED VESSELS FOR PROCESSES
-PIPE TRACING
-VISCOUS MATERIAL
-FUEL OIL LINE HEATING
-ANTIFREEZE PROTECTION
-COMFORT HEATING & HUMIDIFICATION
ENGINEERED FOR:
-EASY INSTALLATION
-AUTOMATIC OPERATION
-CLEAN, FUME-FREE, QUIET RELIABLE STEAM AT THE TURN OF A SWITCH
-ALTERNATE SOURCE OF STEAM WHEN MAIN BOILER IS NOT IN USE
-NO ON-SITE FUEL COMBUSTION
-LOW MAINTENANCE
-NO FUEL DELIVERY/STORAGE PROBLEMS
-FACTORY TESTED - READY TO OPERATE -
|
|
Suitable for industries requiring efficient, high quality saturated steam, including laboratories, hospitals, industrial plants, pilot plants, food and chemical processing applications.
These versatile generators are perfect for almost any application requiring steam from 0-100 PSIG. Each unit is complete with automatic features, including pressure and liquid level controllers, ASME Code pressure vessel and safety valve and are fully tested under power. Each one must pass Sussman's rigid quality control inspection before it is shipped.
|
|
Small size, small capacity Sussman MBA Electric Steam Generators are perfect for applications requiring efficient, high quality steam in laboratories, hospitals, pilot plants and for small, intermittent, low-steam consuming loads.
These generators can be used for standby operations in off-seasons or when a larger boiler is shut down or unavailable. The automatic electronic liquid level controller meets all UL and ASME requirements. A main waterline pressure 10 psig greater than the operating pressure of the steam generator is required for automatic water feeding.
|
|
All wetted metal parts are stainless steel.
Passivation Standard per QQ-P-35 Standard
NOTE: Water with a minimum of 1 meg ohm-cm specific resistivity must be used for proper & safe boiler operation.
STAINLESS STEEL ELECTRIC BOILERS
Sussman SSB Boilers minimize contaminants because all-wetted metal parts are Stainless Steel. Whenever copper, iron or other materials cannot be tolerated in the steam and/or process, a Sussman SSB Stainless Steel Boiler is the product of choice for clean steam.
Designed for:
Pharmaceutical, Chemical Process, Sterilization, Food
Processing, Cosmetics, Autoclaves and other clean steam.
Series 304 stainless steel pressure vessel. Series 316/316L pressure vessel available - consult factory.
Passivation of pressure vessels and fittings
Built to ASME Boiler and Pressure Vessel Codes Sect. I Code M. UL Listed. CSA Certified. National Board registered.
Tested to rigid Q.C. Inspection Procedures.
|
|
|
|
|
|
Multi Function PELLAQUA Water Cylinder
The Pellaqua is not certified for domestic use in the UK; however it is available in the Republic of Ireland.
With its unique combination of a an accumulator tank, integrated heating controls and the provision of instantaneous potable hot water fresh from the mains, the advanced PELLAQUA proves that ÖkoFEN remains faithful to its slogan “always ahead of the game”. The multi-function Pellaqua cylinder is supplied ready for installation with all fittings and electrics included, saving you both time and money.
Characteristics of the PELLAQUA
- Contents: 600 - 1500 litres
- Integrated pump station with up to 2 heating circuits, including optional
solar water heating pump and accumulator loading pump
- Integrated solar heat exchanger with stratification tube
- Accumulator tank
- Optimized for power ranges up to 40 kW
- Self-regulating solar thermal exchanger
- Instantaneous potable hot water, fresh from the mains
- Supplied pre-wired and ready for installation
- Ease and speed of installation allows for significant cost savings
|
|
ACV’s electric boilers are well known for their reliability and their ease of installation and use. They are particularly well-suited for renovating historical sites without a chimney, for office buildings to simplify installation and metering and for isolated, relatively inaccessible homes.
|
|
GENERAL-PURPOSE ELECTRIC BOILERS
ANY STAINLESS
Various applications:
- Heating of small collective
- Technical Warm water
- Reheating of loop
- Agro-alimentary
...
GRETEL - MANUFACTURER OF ELECTRIC BOILERS SINCE 1974
|
|
The comfort of central heating,
advantages of electrical energy!
- Simple and reliable, our boilers can equip any type of circuit (radiator or heating floor).
- Boiler on the built-in ground all
- No storage, brushing or another expenses
- Complete Equipment
- Radiator STAINLESS guaranteed 7 years
GRETEL - MANUFACTURER OF ELECTRIC BOILERS SINCE 1974
|
|
The comfort of central heating,
advantages of electrical energy!!!
- Simple and reliable, our boilers can equip any type of circuit (radiator or heating floor).
- No storage, brushing or another expenses
- Clean and quiet
- Radiator COPPERS guaranteed 7 years
- Settles in any point of the house thanks to its dimensions 600 X.400 X 250
GRETEL - MANUFACTURER OF ELECTRIC BOILERS SINCE 1974
|
|
The ecoTEC plus 937 requires no hot water cylinder or cold water storage tank in the loft. The ecoTEC plus 937 provides a high level of hot water comfort due to its 'actoSTOR' fully integrated storage tank and is ideally suited to properties with higher hot water demands - typically a 3/4 bedroom detached house with one or two bathrooms and an en-suite.
The ecoTEC plus 937 has 2 year warranty and offers a central heating heat output of 28kW.
|
|
ecoTEC pro 24 and 28 combination boilers have the same high build quality as ecoTEC plus combi models, but with a more basic specification.
ecoTEC pro models are ideally suited to properties such as a 1 bedroom apartment / flat with 1 bathroom or 2/3 bedroom semi-detached with 1 bathroom and en-suite.
Note: For new build installations please ensure that the boiler selection meets NHBC guidelines
|
|
ecoTEC exclusive boilers are all SEDBUK Band 'A' rated, the highest boiler efficiency. Both models feature an innovative low energy pump with state of the art electronics, which allows the use of the full range of Vaillant energy saving controls.
All ecoTEC exclusive boilers have a 3 year warranty and offer central heating heat outputs of 27 and 30kW respectively.
|
|
| ... products without information |
| |
|
|
|
|
Reliable heat storage
We offer you solar storage tanks with capacities ranging from 150 to 750 litres. These are Type S water storage tanks equipped with two heat exchangers, which are used in solar heating systems for supplying domestic hot water.
In order to use the solar heat for space heating as well as providing hot water, so-called combination tanks (type K) are often used in private homes. These have an external buffer storage tank that contains a second, inner storage tank.
Optimum corrosion protection
The storage tanks have a double coating of enamel on the inside for optimum corrosion protection and in addition have a magnesium anode whose performance can be regularly controlled using a push-to-test button.
High solar yields through good layering
The high, slim form facilitates the layering of the heat in the storage tank, leading to higher solar yields. The flow-controlled cold and hot water connections are very effective in preventing turbulent mixing of the layers in the tank.
Low losses through high insulation
To ensure that the heat gained remains in the storage tanks, these are covered with a 100 mm-thick insulation jacket. The covers even have an insulation thickness of 150 to 180 mm (depending on the type of storage). In addition the tanks are equipped with 50 mm-thick floor insulation.
|
|
