HEM-1 is an occupancy-oriented HVAC energy management system specially designed for lodging industry. By utilizing an advanced occupancy sensing technology, this system is able to control the guestroom HVAC operation according to the occupancy status.
An advanced microprocessor and sophisticated logic control software enable the system to smartly verify the occupancy status of the room. When guestroom is physically occupied, the system gives the HVAC control to the hotel guest. After the room is vacant, the HEM system will control the HVAC operation as set.
The HEM-1 system ensures no compromise in guest comfort level, while creating significant energy saving to the hotel management.
|
|
Techtile System is fit with Techtile Control, the sophisticated, advanced electronic management system that ensures full, direct control over the system from right inside the home.
It constantly monitors system function, the sun’s rays and the roof temperature, showing the possible changes in state and any malfunctions that could occur.
Techtile Control also acts as a chronothermostat, regulating the temperature in the rooms while Techtile Energy electronically detects any operating anomalies in the photovoltaic tiles, thus permitting direct, simplified maintenance.
Techtile Control has been developed in a range
of colours that currently includes: black - silver - white.
|
|
|
|
|
|
- Programming day laborer or weekly magazine 2 zones
- Manager of energy 2 zones with indicator of detailed consumption
- Time-lag Exemption of 15 minutes zone from 72 hours
- Programmable Absence from 1 to 365 days
- Permanent Exemption by serrated roller
- Locking of the programs
- Unballasting single-phase current cascadocyclique® on 3 or 4 ways in single-phase current (phase by phase in three-phase current) with selection of a way to be lightened as a last resort + ECS
- Detection of inversion of wiring Pilot phase/Wire
- Optimization of the increase in temperature (with option external Radio probes - ref. 6300036)
- Profit of the calculation of C of the RT 2005
- Management of night on-ventilation (with option external Radio probes)
- Food 230 V
- Nonpolarized Bus of communication 2 wire between the modular box and the box of environment
- 3 exits Wire Controls 6 orders + 1 configurable exit ECS at 4th Pilot exit Wire or night ordering of on-ventilation
- Connection TV-information electronic meter or EM.TI.
- Reserve of permanent step of the programs and the clock of 2:00
- Radio bidirectional X2D in the box of environment
- Fixing on box of embedding (Ø 60 mm) or base covered (in option - ref. 6200271)
|
|
- Manager of energy 8 zones, residential or micro tertiary, for the restoration of installations deprived of Pilot wiring Wire
- Programming and unballasting by Transmission current
- Programming independent of 4 automations
- Weekly Programming 8 zones for electric heating via receivers CPL X2D
- 1 program per day (6 adjustable commutations per day at the minute)
|
|
|
|
|
|
The innovative thermoregulator OMNIBUS solved elegantly every applicative situation connected the easily use with a wide function availability.
The most interesting point is that this system invented by EURAPO could grow based on the dimension and characteristic of the system.
The system present an own flexibility employment, based on few elements, easy to install and intuitive on configuration and use.
There are different type of remote console: from the simple Analogue control, to the elegant and complete Display control, to the Infrared control.
An accurate planning made possible the realization of a product with a particular and elegant design: Omnibus could be configured based on the different customer requirement with extreme facility and allow a weekly and seasonal planning of all the functions.
The Omnibus digital system is designed to manage and control the water terminal unit (fan coil units, water cassette units and high pressure ducted fan coil units) for domestic use, residential buildings, public rooms, moreover Omnibus could be integrated with BMS (Building Management System).
Omnibus is a supervisor for small system connected via MODBUS RTU and it can manage one or all of the units in the system at the same time via Web Server (suitable with Internet Explorer 6.xx).
The OCB20 converter permits to connect 10 water terminal unit; it gives information about the units to the Lonmark net and it receives information from the Lon net.
|
|
The Rémo-C module contains two independent relays allowing a room-manager to manage two electrical loads, for example:
-A gas furnace / heater, either for the temperature management (thermostat) and also for day/night function if the furnace supports this function.
-An air-conditioner, for temperature management and also for automatic shutdonw during your absence.
-A water heater or other houshold appliances, to start at a specific time during low-rate hours.
-A strong lighting element, for example, a chandelier, or architectural lighting.
-A small electrical pumps, or electric-valves for sprinkler control, fountain animation, filling up container, etc.
-Interface with an alarm system, to trigger the alarm or to activate it automatically when everybody left the house.
-Interface with a HVAC or other ventilation system.
-To control an electric outlet and other appliances like TV, Hifi, etc.
|
|
Features
Supply voltage 230V +10%/-15%
Assigned frequency 50 Hz
Number of zone of programming 1
Cycle daily
Detection unballasting connection TV-information
Cycle unballasting 3 mn
Many exits wire control 3 exits of 30mA
Composition of modular kit 1 box + 1 box of environment
Outdistance max between modular box and box of order 50 m
Many modules 3
|
|
The manager of energy
He makes it possible to manage several zones and to lighten part of the zone (zone example harms: unballasting of a room). It is connected on the electronic meter of subscriber, which thus makes it possible to question electricity consumption permanently and to lighten the nonpriority circuits in the event of going beyond of contract EDF.
It communicates with the programmer of environment and the local orders of exemption.
Possibility of remote control by Axiophone IP.
Exist in solution "comfort" and "interactive" solution with technology "In One by Legrand" with transmission current.
|
|
|
|
