KUBIC squared downlight with electromagnetic or electronic control gear
enclosed and separated. Made of injected polycarbonate, interior and exterior frame in white. Equipped for two compact fluorescent lamps.
|
|
With the objective of broadening the Konic range, Lamp launches a spotlight that is smaller than the current one, with a diameter of 165mm and a height of 90mm, ideal for low ceilings and for use in corridors and bathrooms.
All of the models are class II and are available for compact fluorescent lamps of 13, 18, 26 and 32 Watts. The Minikonic models, except for the 32W one, all have integrated electronic ballast. There is also a model to be connected directly of 20W.
Just as with the Konic family, there is a great variety of IP20 and IP54 accessories available in white and grey to meet all technical and decorative requirements.
|
|
|
Ceiling/wall - mounted or recessed luminaries featuring direct/diffused light output. Removable composite HPL front panel, diffuser made of UV-resistant, vacuum formed opal polycarbonate surface treated for optimal light distribution. Aluminium die cast body with integral non-dimmable electronic, dimmable analogue or dimmable digital control gear. Compact fluorescent and RGB lamp types available along with maintained and non-maintained emergency lighting systems.
|
|
2858/CG Big
design Emiliana Martinelli
Built-in device, reflected light, integrated in a panel of plasterboard
of 100x100 cm to fix to the plasterboard ceiling.
Internal structure in white lacquered aluminium, for fluorescent or LED.
Complete of electronic ballasts.
structure:
cartongesso
diffuser:
alluminio verniciato
bulb:
6x24W 2G11 FL
dimensions:
hole diameter: 56
hole depth: 18
|
|
|
CCT FLEX: an innovative range of high performance electronic downlight projectors for compact fluorescent TC-T(EL) and TC-D(EL) lamps. Four different reflectors which can be combined with the whole range of compact fluorescent lamps and accessories. Low luminance optics designed to guarantee maximum visual comfort. Ideal for the lighting of working environments.
|
|
Available in:
2 x TC-TEL 26W Gx24 q-3
or
2 x TC-TEL 32W Gx24 q-3
more info: www.orbitbelgium.com
-------------------------------------------------------------------------------
|
|
ABC policy : A
lamptype : compact fluorescent
sockettype : G24q-3
ILCOS code : FSQ G24q-3
ZVEI code : TC-DEL
number of lamps : 2
wattage (W) : 26
light diffusion : direct
input voltage : 230V
gear : int. Gear
dimmable : niet dimbaar
installment : surface
mounting : wand/plafond
dimensions (mm) : ¯ 255 h 153
weight (kg) : 1 6
class : I
application : Interior lighting
standard : CE
protection level : IP40
F-standard : yes
safety distance : 0.5 m
LOR : 0 38
DLOR : 0 3
|
|
Lamp: TC-TE 26-32W
Lamp type : compact fluo
Lamp base : GX24q-3
Light distribution: down
Power supply : 230V-50Hz
Degree of protection: I
Ip rating : IP20
Material: Gegalvaniseerd
Glowtest: yes
Standard: CE - CEBEC
Fixation: ceiling
Mounting: recessed
Weight: 2,14 kg
|
|
PANOS Q High
PANOS Q High provides UGR values < 19 and perfect all-round glare control at 65° < 1000 cd/m2. This means that every requirement for lighting ergonomics is easily fulfilled. An optional safety glass panel increases the protection class of PANOS Q to IP54, if required.
Depending on the design variant, PANOS Q High can be fitted either with one or two lamps. The high luminous flux when fitted with 2 x 42 W, and the uniform, wide-angle light distribution deserve a special mention.
An extensive range of frames and attachments for PANOS Q High or Low guarantees an unmistakable appearance for every lighting project.
|
|
Catalog #:IFV4 / IC482
Description:4" Vertical Compact Fluorescent Lensed
Lamp:13/18/26W TRT
Ballast:Electronic 120/277V
Options:I100, I200, I400, EM, EM-13
Listings:NRTL
|
|
* Designed for compact fluorescent, incandescent, and metal halide recessed downlights.
* Each element is made from premium materials and created by hand.
* Signos6 decorative trim elements are compatible with a range of Prescolite Architektur downlights and are ideal for contemporary architectural applications.
* High purity aluminum Alzak® processed reflector featuring Virtual Source® optical design.
|
|
|
The P-3900 round series of luminaires gives designers total freedom of form and mounting. Whether surface- or pendant-mounted, this fixture creates a ceiling plane guaranteed to enhance the aesthetics of any space. A choice of white or clear prismatic acrylic lenses, as well as T8 or biax lamping are available. The fixture’s housing is one-piece spun steel finished in gloss white polyester powdercoat paint. Standard diameters are two, three and four feet.
|
|
Recessed, modular, luminaires for exposed grid and concealed fix ceilings. Use of T16 (T5) lamps gives very shallow recess depth (58mm). Louvre options for office and commercial applications
Suitable for exposed grid and concealed fix ceiling systems
Easy to install accurately in the ceiling grid
Shallow - 58mm recess depth - modular body
Supplied with 'wedge' support brackets to ensure correct alignment in most ceiling systems
Supplied for plug in electrical connection
High frequency, fixed output, ballasts as standard
Digital dimmable versions, to special order, can be used with Sensa and SensaLink remote intelligent lighting detector modules
Supplied with T16 (T5) linear fluorescent lamps
Mirrorbrite louvre options - specular - 200 cd/m² at 65 degrees for office lighting with intensive VDU use
Satinbrite louvre options - semi specular - 1000cd/m² at 65 degrees for offices
Versions with emergency lighting facility are available
|
|
MIMA
A light from distance "sottopelle".
The construction to passing total and the possibility to paint the diffuser with the color used on the wall create absolute a camouflage effect.
The mimetismo is the fundamental member of plan.
The apparatus reveals its single function in the moment in which it is used.
Fluorescent light bulb 230V - 6W - GX53.
|
|
|
These light fittings are designed for mounting into M600 and M625 panel false ceilings with visible holding tracks, into plaster carton and directly on the ceiling. They are designed for T5 (ø16mm) fluorescent lamps. The light fittings are equipped with electronic ballasts by default, but can be also equipped with emergency power supplies (inverters). They can further be equipped with gesis connectors. They are suitable for illuminating common offices and lounges, as well as spaces with high eye work demands.
|
|
|
Ceiling-mounted luminaire GEO for 1 fluorescent lamp 28/54W T16 with base G5, 230V, direct light emission, housing , powder coated white, symmetic reflector, in steel sheet, white, lamella louvre, powder coated white, halogen-free internal wiring, incorporated HF electronic control gear Protection class I, IP20 L = 1190 mm, B = 150 mm, H = 61 mm
|
|
|
|
|
|
TESS Standard Virtual Skylights and Windows
TESS is the ONLY Custom Design Fabricator of backlit Views to Nature™ as virtual windows and virtual skylights, insuring your project will be unique and of the highest quality. With TESS, your Architects can create designs "outside the box."
Our unique circular frame and grid work guarantees more image and less aluminum T-grid because we can also implement pie shaped wedges instead, should you not wish to use light boxes. We also offer multiple choices of custom wood grain finishes for the circular, oval, square or rectangular aluminum grid work
TESS art panels offer realistic Views to Nature™ due to our photo emulsion process ensuring life-like quality, density, distinct contrast and color saturation. TESS art panels will not fade, crack or yellow at ANY light box depth. The integrity of TESS is known throughout the industry for its unique, unequaled product quality, excellent customer service, extensive image library and diverse product applications.
|
|
TESS Standard Virtual Skylights and Windows
TESS Backlit Views to Nature™ in the form of Virtual Windows and Virtual Skylights are specifically designed to meet the goals of the emerging healthcare market's desire to implement evidence-based design within their medical model and the patient's desire for positive, stress reducing distractions which create supportive and spirit based healing environments. TESS backlit Virtual Skylights and Virtual Windows are easy to install and are recognized as a value-added benefit by patients, physicians and facilities as well as leading equipment manufacturers who view them as a complement to their equipment.
|
|
|
The iMod Duet’s unique design encapsulates two (Duet) micro matt louvres and two subtly ribbed clear polycarbonate refractors, creating a module with a clean, contemporary appearance whilst still maintaining exceptional performance. The module boasts impressive technical aspects including an LOR of 0.72 and LG7 compatibility at 70:50:20 reflectances achieving luminance values below 1500cd/m2 at the 65o cut-off. Optional Mars Red, Lava Orange and Acid Green Fluorescent Inserts can be added to the refractors to create a vibrant ‘neon’ edge lit effect and further enhance the versatility of the module.
|
|
|
The Atol combines ambient and accent lighting in a contemporary style. Incorporating energy efficient T5 Fluorescent light sources with a choice of high frequency gear and discreetly etched glass fascias to create a diffused ambience. Versions with die cast Eclipse luminaires have a choice of light sources adding purposeful accent lighting. The range has been designed to offer flexibility to the Designer wishing to co-ordinate lighting environments. Effective and aesthetically stimulating when used in lines or grid patterns in retail premises, galleries or museums.
|
|
- Incorporates micro-groove regressed extruded aluminum ceiling trim.
- Offered in 4", 6", and 8" widths.
- Available in T5 or T5HO lamp configurations.
- Only 3 3/8" penetration into ceiling plenum.
|
|
- Shallow profile minimally penetrates ceiling.
- Available in semi-recessed or fully recessed versions.
- Extruded aluminum housing and fascia.
- Staggered lamps are standard.
|
|
Adding to our popular recessed modular range, ASD’s new Rhapsody Reflector II offers an extended family of lamp and circuit options.
The single or twin central aluminium louvre controls glare and is complemented with perforated wings to create a decorative appearance with a ‘soft style’ of illumination.
This combination provides highly efficient low glare light distribution with both direct and indirect lighting.
Suitable for use with single or twin 40w or 55w TC-L, 2x or 4x 14w T5 and 2x or 4x high output 24w T5 compact fluorescent lamps.
Provided in: High Frequency, High Frequency Emergency and in Digital Dimmable versions options are also available with corridor function.
|
|
This specification grade surface mount is very low profile and features a variety of door and lens options. All metal parts are powder coated white after fabrication.
PM FEATURES
- Low profile, 3-1/2" depth
- Choice of doors from steel to extruded aluminum, open from either side
- Diffuser easily removable for lamp access and cleaning
- Heavy gauge steel housing with embossments for added strength
- Mitered corners
- All parts are powder coated white and painted after fabrication
- Prismatic acrylic lens standard
- Spring loaded steel latches
- Available in pendant mount
- UL listed 1598, cUL or CSA. Damp Location standard
|
|
General
Order code 2831.2G4 alu grey
Mounting Ceiling recessed
Lamps description 2 x TC-D 26w G24d-3
Color Alu grey
Notes HPF on request
Optical
Reflector finish Anodized pure aluminium
Aiming Fixed
Luminous distribution symmetry Symmetric
Downlight symmetry Symmetric
Electrical
Control gear availability Included
Control gear mounting Integral or Remote
Control gear description Conventional with LPF
Emergency Without
Voltage (V) 230
Physical
Place of use Outdoor
Cutout shape Rectangular
Cutout length (mm) 335
Cutout width (mm) 165
Recessed depth 160
Construction materials Corrosion resistant die-cast aluminium
Weight (kg) 4.2
|
|
General
Order code PLATO/N 1/28W
Mounting Ceiling recessed
Lamps description 1 x T16 28w G5
Color White
Optical
Optical system description Louvre
Reflector finish Anodized pure aluminium
Aiming Fixed
LOR (%) 77
Downlight symmetry Symmetric
Uplight symmetry No uplight
Electrical
Control gear availability Included
Control gear mounting Integral
Control gear description Electronic
Emergency Without
Voltage (V) 230
Physical
Place of use Indoor
Ceiling type Module 600
Cutout shape Rectangular
Cutout length (mm) 1196
Cutout width (mm) 296
Recessed depth 55
Construction materials Sheet steel
Weight (kg) 10.1
|
|
|
Complete family of luminaires, in two different designs, and with a wide variety ol models and versions especially designed to (over any illumination project In commercial and industrial areas, offices, learning centres or leisure venues.
|
|
|
Luminaries for mounting or hanging with high quality luminous properties mixed together with high quality design and materials.
|
|
|
The PMC SC12R/14R Series is a direct/indirect recessed fixture, with solid center basket gives softer indirect accent lighting. SC12R/14R fixtures have powder coated housings, with precisionformed, high reflectance, enamel reflectors for optimal optic efficiency. Fixtures are UL listed, and have standard electronic ballasts. Each fixture is lamp-tested at the factory before shipment.
|
|
The PMC Steel Squares series is one of our most popular lines can be modified with a full range of diffusers and light sources, making it a luminaire to consider for new installations and retro-fit applications.
All fixtures have epoxy powder coated housings, with precision-formed, high reflectance (Minimum Reflectance Factor 90%), enamel reflectors for optimal efficiency. Fixtures are UL listed, and have standard electronic ballasts. Each fixture is lamp-tested at the factory before shipment.
|
|
|
|
