By offering the 3 pipe GHP air conditioning system in Europe, SANYO provides the greatest choice and flexibility to solve any power problem or site requirements.
Simultaneous heating and cooling for total control
Diversity ratio 50% - 200%
Extended pipe runs (total 780m)
Silent mode offers a further 2dB(A) reduction
10,000 run hours between engine service intervals (equivalent to one maintenance every 3.2 years*)
Connectability of up to 32 indoor units
Full heating capacity down to -20°C
No defrost cycle |
|
Water chiller
WSAN-XSC: heat pump
WSAT-XSC: cooling only
Air cooled
Outdoor installation
Capacity from 163 to 493 kW
The R-410A SPINchiller series presents a new concept of chiller offering:
-EFFICIENCY that increases as the heating load decreases, while guaranteeing maximum requested load when necessary. SPINchiller always ensures maximum comfort with very high efficiency and consequently considerable energy savings;
-a modular approach. Several basic units may be connected together to form a single structure according to the required capacity. This allows high production standardisation and therefore utmost operating RELIABILITY;
-simple unit-system combination, since these units are SELF-ADAPTING to the characteristics of the actual system, thereby avoiding delicate, timeconsuming calibrations. Easy connection to the service system plus a simple control system and easy maintenance drastically reduce work requiring specialised personnel with consequent reduction in installation costs;
-extended operating limits to keep the system running, even under exceptional start-up and load conditions;
-customisation of the unit, also for special requirements both in the civil and technological air-conditioning sphere, thanks to the many available optional accessories. The ECOBreeze and HydroPack accessories in particular enhance the qualities of flexibility and energy efficiency. The latter, for example, consistent with the concept of modularity, has several pumps in parallel with the possibility of reserve pump, to monitor the system load variations better and to regulate the water flow in the critical system starting (or restarting) stages so that outside servicing is avoided. |
|
Water chiller
WSAN-XEE: heat pump
WSAT-XEE: cooling only
Air cooled
Outdoor installation
Capacity from 24,3 to 72,2 kW
Liquid chillers and heat pumps of the ELFOEnergy WSAT-XEE and WSAN-XEE series are units designed for outdoor installation and best energy efficiency in relation to their reduced size.The ELFOEnergy series has been the turning point in the evolution of chillers.Every unit has been conceived and made by applying state-of-the-art technology,emphasising the qualities of EFFICIENCY, SELF-ADAPTATION and EASY INSTALLATION that distinguish this product Thanks to its constructional and electronic peculiarities, ELFOEnergy permits:
-high energy efficiency, in particular during partial-load operation, thanks to the use of two compressors with different capacities that work on a single refrigerant circuit;
-Eurovent energy efficiency classification class "A" in heating operation,also in full load condition;
-adaptability of operating parameters to the load conditions of the connected system, thereby optimising consumption, efficiency and working life of the parts;
-easy, quick installation thanks to the standard hydronic group and the factory test carried out prior to dispatch;
-installation of hydronic group with non-standard working head pumps or with double pump. |
|
Packaged air-conditioning unit
Heat pump
Water cooled
Horizontal indoor installation
Ductable
Capacity from 8 to 31,5 kW
Room control HID-T1 for wall-mounted remote installation with functions of:
-manual or automatic summer/winter selection
-temperature setting
-manual setting of fan speed
-other useful functions
High efficiency, low noise, single compressor EVHSpace units are available in 10 sizes, backed up by a complete range of accessories.They are ideal for air conditioning in shops, shopping centres and open space offices, etc. and can be installed either in a closed ring (WLHP) configuration or, more commonly, in a lost water configuration.Thanks to their compact size and easy maintenance, they are the perfect choice for installation above false ceilings.Air distribution is ducted while air return can be either ducted or direct from the surrounding environment.Because they can function in heating and cooling modes, these units ensure real all-year-round comfort.A microprocessor control system provides important additional control and adjustment functions, all of which can be controlled by a room controller or B.M.S. over a serial communication line. |
|
Packaged air-conditioning unit
CH: heat pump
CA-HL: cooling only
Water cooled
Horizontal indoor installation
Ductable
Capacity from 8,28 to 33,3 kW
The single-compressor CA-HL and CH units come in 10 sizes with a complete set of accessories and are distinguished by their high efficiency and low noise.They are intended for air-conditioning shops, shopping areas in general, openspace offices, etc. They are applied in closed loop (WLHP) or, more generally, in open loop water systems.They are ceiling-mounted, either exposed or inserted inside a suspended ceiling. Installation is simple also thanks to the reduced size and maintenance is easy to carry out thanks to the full accessibility of all the parts from just one side. The conditioned air is distributed via ductwork, while the air intake can be either direct from the room or ducted.The automatic mode of operation ensures comfort throughout the year, whether heating or cooling, without seasonal switching over. Microprocessor regulation also allows other important functions of control and regulation to be carried out that may all be transferred to a remote unit or BMS through a serial communication line. |
|
Packaged air-conditioning unit
Heat pump
Water cooled
Roof Top
Capacity from 42,3 to 300 kW
The CRH-XHE packaged air-conditioning units are installed outside the spaces being served. They come in various capacities and with a vast range of accessories. They are intended for the air-conditioning of large rooms or areas and are applied in closed or open loop water systems. Designed to reduce work on site to a minimum, these units have been created for continuous operation with maximum energy saving through an extremely intelligent, advanced management of energy, supplying it only when and where needed. They are extremely versatile units with three airflow settings: standard, high and reduced. They may also be adapted to all requirements thanks to many differing installation possibilities. |
|
Packaged air-conditioning unit
Heat pump
Water cooled
Vertical indoor installation
Ductable
Capacity from 10,7 to 78,9 kW
The CH-V units are all-in-one models, that is, they incorporate all the necessary components for system operation. They come with a complete range of accessories and are distinguished by their high efficiency and low noise.They are intended for air-conditioning shops, shopping areas in general, openspace offices, etc. They are applied in closed loop (WLHP) or more generally in open loop water systems.Thanks to their compactness, vertical installation is easy, whether floor-mounted and exposed or inside a special technical space. Maintenance is also easy to carry out. Conditioned air distribution is via ductwork or plenum; the air intake (front, rear or from below) is directly from the room or via ductwork.The automatic mode of operation ensures comfort throughout the year, whether heating or cooling, without seasonal switching over. Microprocessor regulation also allows other important functions of control and regulation to be carried out that may all be transferred to a remote unit or BMS through a serial communication line. |
|
Packaged air-conditioning unit
Heat pump
Water cooled
Horizontal indoor installation
Ductable
Capacity from 1,72 to 5,30 kW
Room control HID-T1 for wall-mounted remote
installation with functions of:
-manual or automatic summer/winter selection
-temperature setting
-manual setting of fan speed
-other useful functions.
EVHRoom water-air heat pumps are low power (1,7 - 5,3 kW) single compressor pumps for installation in WLHP loop type or lost water systems in shopping centre outlets, hotels, offices and office blocks.These cleverly designed monobloc units are extremely compact and efficient,and can be installed in next to no time, using a vast range of options and accessories.A reliable on-board microprocessor unit automatically monitors alarms and can dialogue with remote management systems. |
|
Water chiller
Water cooled
Indoor/outdoor installation
Capacity from 197 to 511 kW
The WSH-SC units belong to the SPINchiller family and therefore feature high energy efficiency, self-adaptation and reliability.
-Compactness: when designing the unit special attention was paid to reducing the dimensions of the front as much as possible. The width in the units up to 500 kW capacity has been reduced to just 85 cm so that they can pass through normal doorways.
-Special attention has been paid to making connection to the service system easy so that work requiring specialised personnel is drastically reduced thereby allowing installation costs to be cut considerably. This same policy ensured that attention was paid to easiness of controls and maintenance on all the most sensitive parts.
-EFFICIENCY that increases as the heating load decreases, while guaranteeing maximum requested load when necessary. SPINchiller always ensures maximum comfort with very high efficiency and consequently considerable energy savings;
-The particular abundance of optional accessories allows customisation of the unit, also for special requirements both in the civil and technological air-conditioning sphere. In particular the optional for the HydroPack water circulating unit, consistent with the concept of modularity, has several pumps in parallel (up to 3), to monitor the system load variations better and to regulate the water flow in the critical system starting (or restarting) stages so that outside servicing is avoided. |
|
Water chiller
WDH: cooling only
Water cooled
Indoor installation
Capacity from 408 to 1537 kW
The experience gained by Clivet in the high-capacity chiller sector has resulted in the WDH series, with the following features:
-EFFICIENCY - Eurovent energy efficiency Class A and B thanks to the new high capacity screw compressors and to the shell-and-tube exchangers specially developed for the gas R-134a: the best compromise to boost efficiency while limiting costs. The compressors are managed with continuous adjustment of the capacity. The heat exchangers are specifically sized for best adaptation to the other parts of the refrigerant circuit. The latter is fitted with an economiser exchanger for further operating efficiency;
-SELF-ADAPTATION - New, modern and intelligent electronic control directly developed by Clivet. This customisation allows better management of all the circuit components.Continual adapting of chiller operating parameters to the load conditions of the system in which it is installed reduces consumption while the working life of the parts increases;
-STURDINESS - Load-bearing frame in enamelled hot-galvanised sheet metal with semi-hermetic double-screw compressors and shell-and-tube evaporator ensuring reliability and constant performance.
These units may be combined with the dry coolers of the REM series. |
|
FRYO 7 – 20 SERIES
WATER CHILLERS AND HEAT PUMPS FOR LARGE OR MIDDLE-SIZED ENVIRONMENTS
FRYO 7 – 20 SERIES water chillers are ideal for the climate control of any environment (homes, offices, factories, etc.). They are safe, reliable and easy to use.
The S letter in the water chiller’s name stands for the presence of an inertial storage tank (20 liters for 7 and 8 models, 40 liters for 15 and 20 models) to reduce the number of acceleration points of the compressor. The P letter means that the water chiller can also function as a heat pump.
|
|
LCW Package water cooled chillers and heat pumps
LCW water chillers and heat pumps are designed for indoor installation in both residential and industrial applications with 24 h/day operation. They are developed in a completely careened execution for an absolute noisless of the assembly.
The innovative design philosophy drawn to the creation of a unit with very reduced height (1,5 m for all the range) and water connection to the top of the unit, where together with an already preassembled internal piping means a reduction of installation costs and of technical space. All the sites are provided with refrigerant circuit and, starting from site 180, the units are provided with 4 compressors in tandem configuration with a very flexibility in the capacity modulation, reduced in rush currents and higher at the part loaded operation.
|
|
EHW Residential heat pump
Water-water chiller with water circulating assembly utility side
Optional: Remote controller (cod. 07225040).
Optional: Pressure valve for cooling mode (part no. 07225010 or part no. 07225020), for reducing condenser water consumption. In chiller heat pumps, this valve must be by-passed by another valve when the unit i
|
|
Heat pumps habitat and small tertiary
Ecological comfort at low-costs with a tax credit of 50%.
The air/water cast solid reversible heat pumps are perfect for heating/refreshing floor applications low temperatures or fan coils. To use renewable energies, with a cast solid and compact product facilitating a fast and discrete establishment in outside. |
|
9 sizes from 19kW to 79kW
Chlorine free R407c green refrigerant
Scroll compressor design - Single circuit
Integrated Hydronic ModuleIntegrated Hydronic Module
High Static Axial Fans for Ducted Applications - 100 to 150 Pa
Direct Drive Axial Fan : no belt, no air flow adjustment at start-up
User friendly Prodialog Plus control with direct display machine main parameters : temperatures, pressures and CCN Clock board functionalities as standard*
|
|
12 sizes from 40 to 222kW of Heating Capacity
Easy installation : Aquasnap includes an integrated hydronic module and a standard disconnect switch
Exceptional quiet operation: all units have scroll compressors and low noise shrouded Flying Bird II fans.
Chlorine free R407c green refrigerant
User friendly Prodialog Plus control with direct display machine main parameters : temperatures, pressures.....
Easy integration into any building thanks to reduced footprint and low profile
Standard Protection Grills
|
|
Aqualis 2
Air-source reversible heat pump for heating and cooling of individual homes and small businesses. May be connected to emitters that radiate gentle heat, such as underfloor heating and cooling systems, terminal units (such as fan coil units and water cassettes) or low-temperature radiators. May be installed in new or renovated housing and buildings to replace or be used in conjuction with a gas or oil-fired boiler. Designed as standard for outdoor installation without any special weather protection.
Eight models available
Heating capacity: 6 to 19 kW
Cooling capacity: 5 to 18 kW
- Complete packaged unit housed in a corrosion-resistant recyclable plastic casing,
- Scroll compressor,
- Water-cooled brazed-plate heat exchanger,
- Low-speed propeller fan,
- Hydraulic module with accelerator pump and expansion vessel,
- Microprocessor-based control unit with MICROCONNECT two-wire remote control and self-regulating functions,
- R-410A refrigerant. |
|
Strong points:
Economies
Up to 3,28 of coefficient of performance, which means that for one kWh consumed, the heat pump restores up to 3,28 kWh. Up to 75% comparatively on the fuel and propane and up to 50% on natural gas
To be well and total comfort in summer as in winter
The restitution of thermal energy is done by the means of a floor heating low temperature, which creates a comfort exceptional heating. The installation can be supplemented by a ventilo convector to ensure airconditioning in summer.
Ecology
Safeguarding of the environment by avoiding the recourse to the fossil energy resources. No rejection in the atmosphere
Certification
Products certified by CSTB, 410 has
Simplicity of setting in %u0153uvre for the fitter
- easy to pose, not sensors to be buried, not drilling
put it in %u0153uvre does not ask particular refrigerating competences (the circuit refrigerator being closed and being charged, it is ready with employment)
Simplicity with the daily newspaper for the user
Once installed, the heat pump is extremely easy to live:
- an easy daily newspaper: more provisioning fuel or gas to be managed
- a durable reliability thanks to a reduced maintenance
- a discretion of the apparatus thanks to the silence of well studied operation
- an heating or a comfortable cooling
- a remote control: the order installed on the machine can be simply moved inside, thanks to two cables. That makes it possible to manage all the parameters of MAGNA remote AIR.
|
|
Perfect for low energy houses, the Vitocal 300 can provide the entire heating demand, even on cold days. Benefits include high operational reliability and very quiet operation.
This range has a high performance factor: COP to 4.61 for brine and 5.6 for water. The standard control is a weather compensated digital heating circuit unit, with integral cooling function, menu guided operation and integrated diagnostic system. Single stage available from 6kW to 12kW. Two stage from 12kW to 107kW. A Vitocal 300 BWC version is available factory fitted, with integrated brine pump, heating circuit pump, electrical auxiliary heater, safety assembly, with safety valve, pressure gauge and air vent valve. |
|
Aqualis Caleo
Air-source heat pump for heating of individual homes and small businesses. As it operates in the high temperature ranges (+65°C for an outdoor temperature as low as -12°C), it can be connected to emitters of all types, terminal units (such as fan coil units and water cassettes) or radiators. May be installed in new or renovated housing and buildings to replace or be used in conjunction with a gas or oil-fired boiler. Provides complete autonomy and offers comfort and real energy savings when combined with a domestic hot-water tank and a buffer tank. Designed as standard for outdoor installation without any special weather protection.
Three models available
Heating capacity: 13 to 19 kW
- Complete packaged unit housed in a corrosion-resistant recyclable plastic casing,
- EVI (enhanced vapour injection) scroll compressor,
- Water-cooled brazed-plate heat exchanger,
- Variable-speed propeller fan,
- Inrush current limiter as standard on single-phase model, as required by French standard NF C 15 100,
- Hydraulic module with accelerator pump,
- Microprocessor-based control unit with MICROCONNECT two-wire remote control and self-regulating functions,
- R-407C refrigerant,
- Domestic hot-water tank optional. |
|
Aurea 2
High-temperature ground-source (earth or groundwater) reversible heat pump for heating and cooling of individual homes and small businesses. Built with all the necessary hydraulic components on the sensor and emitter side. May be connected to emitters that radiate gentle heat, such as underfloor heating and cooling systems, terminal units (such as fan coil units and water cassettes) or low-temperature radiators
Seven models available
Heating capacity: 9 to 36 kW
- Complete packaged unit,
- Coated, corrosion-resistant galvanised steel casing,
- ABS exterior panel,
- Free-standing inside frame separated from main frame by vibration isolators,
- Scroll compressor,
- Water-cooled brazed plate heat exchangers,
- Hydraulic module on both exchangers, with accelerator pump and expansion vessel,
- Microprocessor-based control unit with MICROCONNECT two-wire remote control.
- Inrush current limiter as standard on single-phase model, as required by French standard NF C 15 100
- Domestic hot-water tank optional. |
|
One of the components main part of the systems "Heat Sun" is heat pump GEOCALOR.
An heat pump (CAP) is a machine intended to ensure the heating of a room starting from the collecting of an external heat source whose temperature is lower than that of the room to heat.
Heat pumps GEOCALOR thanks to new technologies of thermodynamics, record the level of the temperature of external collecting, to carry it on the level of comfort desired for the heating of the habitat.
The solar energy stored by the ground is thus recovered either:
· By a standard sensor "network of surface", consisted a network of tubes buried in the garden.
· By a standard sensor "depth pins" realizes in a specific drilling.
· By a standard system "tablecloth" using surface water such as present in opened wells, brooks, pond, etc.
· By a "atmospheric sensor" directly recovering the solar radiation or the heat of the surrounding air.
|
|
One of the components main part of the systems "Heat Sun" is heat pump GEOCALOR.
An heat pump (CAP) is a machine intended to ensure the heating of a room starting from the collecting of an external heat source whose temperature is lower than that of the room to heat. |
|
... see all the products in the category
