It’s one of the new our products we introduced in the International market to meet our customer’s requirements.
By a thorough analysis of the more advanced technologies in the worldwide market EN.GI.EI. can assure a reliable system with high quality materials.
All components interacts amoung themselves and assure an optimal working and a long life with the best ratio quality-price.
The Tilt and Turn Kit is composed of an ambidextrous mechanism adaptable to windows having a width between 365 mm. and 1.300 mm. and a height between 500 mm. and 2.450 mm.
Supplemental arms are envisaged for applications where the widht is greater than 1.300 mm. and supplemental closures where the height exceeds 1.200 mm.
The mechanism is also provided with a special system for the protection against incorrect manoeuvres, forced entry protection , various adjustment devices and It’s characterized by an installation performed using a simple and intuitive procedure that reduces the installation times.
Another , but not the last important characteristic is provided by the fact that It’s possible to match the B 101 cremone aesthetically matching the kit with the rest of normal hinged opening windows.
It should be noted that the height of the hinge unit is equal to 100 mm. adapting itself to the aesthetics of the standard hinge closing window.
|
|
OPEN JOINT HINGE
CHARACTERISTICS
Reversible type hinges designed and made with a particular fixing system. In fact, in the materials provided there are 4 special stainless steel screws; the particular shape of these screws, once the hinge is screwed on, create interferences on the door frame, considerably increasing hinge bearing capacity. In addition, the fixing plates in stainless steel furnished with, are knurling on sides to permit more fixing tightness. The results achieved are the fruit of technical tests that ENGIEI has conducted on all types of sections.
MATERIALS AND COMPONENTS
1 pc extruded aluminium male hinge
1 pc extruded aluminium female hinge
1 nylon bush
2 nylon caps
1 galvanized pin d. 8xL52
2 fixing plates inox aisi 430
4 M5 screws inox aisi 304
FINISHES
Anodized: silver, bronze, electro colour, black elox
Ral: standard, colour chart
Specials: gold
PACKS
50 pcs in each pack
OPTIONAL: On request
- the hinges can be supplied with pin in stainless steel d.8 x L.52
Also available with three wings version |
|
QUIK INSTALLATION QUIK HINGE
CHARACTERISTICS
The QUIK hinge designed and made by ENGIEI, to ensure rapid application and reduce the installation times, thanks to the way of the plate and steel pin are made up. The tolerances, between the sections can be taken up, facilitating installation on the doors. The use of the stainless steel for the pin's anchoring plates and screws are the guarantee of product quality. It also distinguishes the validity of the firm ENGIEI which is truly market-oriented and intent on constantly improving the quality of it's product and it's services as well.
MATERIALS AND COMPONENTS
1 pc extruded aluminium male hinge
1 pc extruded aluminium female hinge
1 nylon bush
2 stainless steel securing plates aisi 430
4 M5 steel screws aisi 304
1 stainless steel pin, d. 7x L.76
FINISHES
Anodized: silver, bronze, electro colour, black elox
Ral: standard, colour chart
Specials: gold
PACKS
50 pcs in each pack
QUIK INSTALLATION QUIK HINGE |
|
HERCULES HINGE
CHARACTERISTICS
This hinge has been designed for safety or armoured doors because of its installation and capacity characteristics. The plate covering the securing screws is fixed with a dowel from the inside of the hinge and can only be removed when the door is open. With the components provided, spring fixing plate, guided by a 6 mm diameter threaded rod and the template (optional for drilling), easy use and simple installation are guaranteed.
MATERIALS AND COMPONENTS
1 pc extruded aluminium male hinge, centre distance 21
1 pc extruded aluminium female hinge, centre distance 40
2 nylon eccentric bushes
2 extruded aluminium covering plates
1 pin inox d. 12xL67
2 extruded aluminium fixing plates
2 springs for the plate
2 thick washers
4 M8x25 hexagonal headed screws
4 knurled guide bushes, d.8x11
2 M6x10 pointed inox dowels
FINISHES
Anodized: silver, bronze, electro colour, black elox
Ral: standard, colour chart
Specials: gold
PACKS
10 pcs in each pack |
|
HINGE TRIADE
CHARACTERISTICS
This hinge has been designed to adapt to any kind of existing section whether it is made in aluminium, iron or wood. Its characteristics is the fixing system whitc is very simple but extremely flexible.
MATERIALS AND COMPONENTS
1 pc extruded aluminium male hinge
1 pc extruded aluminium female hinge
nylon bush
nylon caps
pin
screws
plates
FINISHES
Anodized: silver, bronze, electro colour, black elox
Ral: standard, colour chart
Specials: gold
PACKS
100 pcs in each pack |
|
Optimum performance for light-weight doors
Bridge2 is the comb hinge for light-weight doors and windows made using window profiles. It is recommended for use in applications that involve particular cross stress on the pin axis, for example in the case of a very wide sash or an inward or outward opening window.
Bridge2 can be used for load capacities of up to 90kg.
The special shape of the hinge and the channel fixing plates allows fast assembly, even on openings that are already installed, adn perfect positioning of the hinge. Thanks to the removable pin it is possible to separate the sash from the frame without having to dismantle the hinge.
The hinge is supplied fully ready-assembled, with the sole exception of the frame fixing plate. The wide range of articles allows the hinge to be fitted on flush and overlapping sashes made from all the main window profiles. |
|
Domina is the practical and functional front application hinge for the construction of doors with door profiles. Notable for its simple and linear design, which integrates perfectly with the main profiles, it is available in 2-leaf and 3-leaf versions.
The pressure and side adjustments can be carried out easily after door installation, without lifting the sash. The strenght of the hinge enables it to withstand load capacities of up to 120kg.
The hinge comes in a vast range of models, each differing in terms of the step and the sash-frame side C/C distance. This enables the hinge to be applied on almost all of the profiles available on the market. |
|
Hinge for door equipped of horizontal and vertical adjustments. Fully integrated with Loira Top and Loira Baby where it shares the fastening set and the drilling system.
3 part hinge in extruded aluminium, rotating pivot in rectified stainless-steel Ø12mm, equipped of anti-theft device, rotating eccentric bush and adjusting in Delrin.
|
|
VENICE hinge for Eurogroove profiles.
Hinge body and counterplates in extruded aluminium, adjusting bush in Delrin, pivot and screws in stainless steel, caps. in nylon. Hinge suitable for doors manufactured from window profiles. It is fitted directly on profile grooves with no need of further machining. It is supplied with pre-assembled counterplates and can be horizontally ( /- 1mm) adjusted when the door is in the closed position. |
|
| The hinge body is in anodised extruded aluminium or painted. The rotating pivot in stainless steel. The rotating bush in self-lubricating nylon. The fixing screws and plates are in stainless steel and pre-mounted. It's also possible to use eccentric-bushes, to adjust the distance between the sash and the frame. |
|
| Grip three-leaf hinge suitable for European groove profiles. Its shape as well as its exclusive fastening system ensure safe application on particularly large and heavy sashs. It is preset for the assembling of a stainless steel break pin preventing considerable heavy sashs from sliding down. Hinge body in extruded aluminium, anodised or painted. Rotation pivot in stainless steel. Rotation bushes in self-lubricating nylon. Pre-assembled fastening screws and plates in stainless steel. |
|
