1) Flange: Solid sawn pine lumber flange or LVL flange
2) Web: Pine plywood
3) Length: 2.5, 2.9, 3.3, 3.36, 3.9, 4.5, 1.9, 5.9
4) Specification: H200X80X27X40mm
4) Weight per running meter: 5.0kg
5) Bending: 3/720
6) Permissble bending moment: M=95kn/m
7) live load: 1613.3kn/m3
8) Permissible shear force: Q=595KN
9) Characteristic: Low cost, high straight, weight light. Generally be used, adapt to E2 environmental standard. High standardization of product parts, good to be reused.
|
|
H20 Beam
i beam(i-josit)
length cm:180/245/290/330/360/390/490/590
Live load(bending stiffness):max 500kn/m2
material: made of high-grade solid sawn pine lumber and pine plywood,LVL pine plywood
glude:MUF warterproof glue
color:yellow
Overall beam depth H: within 1 mm
Flange width and depth: within 1 mm
Web thickness: within 0,5 mm
Maximum moisture content by the time of assembly is 18 % for the timber flanges and 10 % for the web boards.
The system product parts standardizes degree is high, reused well, meet the environmental protection request.
|
|
|
The Kaufmann HT20plus formwork timber beam is a solid I-beam used for concrete formwork construction. The height of the beam is 20 cm and it is available in different standard lengths. The patented, stable synthetic cap prevents premature splintering at the high sensitive chord ends. The HT20plus is successfully used for many years worldwide - in over 50 countries.
|
|
A) Flange:solid sawn pine lumber flange
B) Pine plywood web.
C) WBP phenolic resin (professional glue for H Beam)
D) Painting on the surface of flange and web: with yellow, waterproof, fireproof, rot-proof and frozen-proof
painting, and the painting is environment friendly, meeting the environmental protection request.
Weight per running meter: 5.2-6.5kg
Bending moment -- max. 5kN/m
Shear force: min 11.0kN
Bending: max 1/500
Live load (Bending stiffness) Max 500kN/m2
H.S. Code 2007: 44186000.90
|
|
Contract Grade Beam Seating
Freestanding or Floor Mounted (Hardware not included)
Multiple Units Connect in Line (see Option Pricing for required Linking Devices)
Convenient Floor Levelers
High Impact Polypropylene Seats and Backs
Upholstered Seat and Back Pads Optional
Optional Arms on each Seat or Sides Only
Table Tops Optional, Black or Grey Laminate, 17.75” x 17.75”
Simple Assembly Required
|
|
Contract Grade Beam Seating
Freestanding or Floor Mounted (Hardware not included)
Multiple Units Connect in Line (see Option Pricing for required Linking Devices)
Convenient Floor Levelers
High Impact Polypropylene Seats and Backs
Upholstered Seat and Back Pads Optional
Optional Arms on each Seat or Sides Only
Table Tops Optional, Black or Grey Laminate, 17.75” x 17.75”
Simple Assembly Required
|
|
|
A proven system for over 25 years, Series 3000 curtain wall is a “fully captured” wall system meeting the highest performance requirements. Suitable for medium to high-rise curtain wall installations, Series 3000 is available in 2-1/2" or 3" wide profiles. The use of interior trims at vision areas only, meaning a cost-savings to the building owner. Interior trims are thermally isolated from the exterior climate conditions. Series 3000 can accommodate multiple finishes, allowing for non-matching interior and exterior profiles. The latest in architectural coatings are available including high performance Kynar paints as well as a choice of anodic coatings. The time-proven design of the Series 3000 I-Beam curtain wall can be custom engineered to the specific requirements of any project.
|
|
|
|
