REDWATCH MULTI, a revised and upgraded version of our proven REDWATCH® technology, has a significantly more advanced high quality colour/mono camera with varifocal lens integrated with the PIR to deliver a combined/detector sensor. The new product also has the benefit of a higher mounting height. The option of a standard 2.3 Metre mounting height providing 50 x 30 metre detection range, or a 30 x 20 metre detection pattern at an increased height of 4 metres.
As with all products in our detection range, REDWATCH MULTI is particularly adept at countering one of the biggest headaches for remote monitoring centres, installers and end-users associated with false alarms in outdoor detection: miss-match of the camera lens view and the detection pattern. RedWatch multi now easily deals with issues caused by changes to the operation requirement on the remote site; a slight alteration to the viewing angle of the camera now means that the detection pattern will follow, perfectly.
Features
BS8418 Compliant
Colour/mono & monochrome versions
Matched Fields of view
Operating temperature -25°c to 60°c
Mono 570 TVL 8.0mm lens 0.08 lux
Colour/Mono 3.8-9.5mm Varifocal Lens Colour
0.5 lux 510 TVL Mono 0.03 lux 480TVL
Triple electronic processors
Gold coated optics
Triple dual element sensors
Patented optical array
Patented double conductive shielding
Accessories
Sun/snow shield - LRPMIDIHOOD
Walk tester - OPM-WT
Pole mount bracket - LRPSCA
Visual alignment aid (supplied)
|
|
weatherproof outdoor camera with combined halogen spotlight and advanced motion sensor. The DCL-400 is designed to be used with WT-50 digital event recorder, to provide excellent visual coverage of a property. The light angle and sensor camera angle can each be adjusted separately, allowing for perfect alignment of the DCL-400 to the target area to be monitored.
The detector incorporates Optex patented technologies such as Double Conductive Shielding, which minimises false alarms from vehicle headlights and direct sun light, and Quad Zone Logic, which enables the sensor to discriminate between humans and small animals, minimising the chance of accidental activations. The unit is wall, ceiling or pole mountable and contains an adjustable photocell to ensure that the light only activates in darkness, unless manually overridden through the WT-50.
Features
Built-in advanced motion detector and halogen spotlight
Adjustable Sensor Camera angles and Spotlight angles
Aesthetic design to suit any building exterior
|
|
-Day & night functionality
-Up to 45 frames per second in VGA resolution (640 x 480 pixels)
-Simultaneous Motion JPEG and MPEG-4
-Multi-window motion detection
The AXIS 221 Day & Night Network Camera is a high performance camera for round-the-clock surveillance over IP networks. The camera provides high quality images under all lighting conditions, which makes it an ideal solution for indoor/outdoor applications, e.g. surveillance of buildings, roads, parking areas, garages, railway stations and airports.
|
|
- 1/3" Super HAD Progressive CCD
- Day & Night (Moving filter)
- Horizontal resolution: 540(color)/570(B/W) TV Lines
- DNR (Digital Noise Reduction)
- Minimum scene illumination: 0.0005(color)/0.00005(B/W) Lux
- WDR (Wide Dynamic Range) - (SCC-B2313/B2013P is not available)
- 24ea Privacy Zones
- Motion Detection
- 2X D-Zoom
- OSD (On Screen Display)
- RS485 remote control
- AC24V / DC12V (B2013/B2015P: AC220V only) |
|
- Horizontal resolution : 520 TV Lines
- Minimum scene illumination : 0.15(color)/0.015(B/W) Lux
- Compact size of 85(ø)x54(H)mm
- Pan/Tilt adjustment to a wide range of angles
- Sharp image quality, with an excellent signal-to-noise ratio (50dB)
- Easy to install (Ceiling-mountable)
- Exterior Color:
SCC-B5203S (Silver)
SCC-B5203 (Black) |
|
Hi-Resolution DSP(Digital Signal Processing)
1/3" 470,000 pixels Super HAD CCD
Horizontal Resolution of 540 TV Lines
Back Light Compensation Circuitry
External Synchronization with Linelock
Accepts 2 Types of Auto-Iris Lenses (DC/Video)
Accept CS/C-Mount Lens (with C-Mount Adaptor)
Power Input (AC24V/DC12V Compatible)
Built-in Ground Fault Isolation Transformer |
|
- 1/4" Ex-View CCD 410K/470K
- DIS (Digital Image Stabilizer)
- 32X Zoom Lens (digital zoom: 10X)
- Minimum scene illumination : 0.002(color)/0.0002(B/W) Lux
- Day & Night
- 128X WDR (Wide Dynamic Range)
- Motion Detection (with adjustable zones and sensitivity levels)
- Privacy Protection that Allows up to 8 Privacy Zones
- Remote Control through RS485
(using SSC-1000 and SSC-2000)
- Sharp image quality,
thanks to an excellent signal-to-noise ratio (50dB) |
|
1/4" Ex-view P/S 410K CCD
480 TV lines of Horizontal Resolution
Built-in X22 Optical Zoom Lens (X10 D-Zoom)
Sensitivity : 0.2 Lux (X4 Sens-up, Color)
360º Endless PAN (Slip-ring)
Preset Speed : Pan (400º /sec), Tilt (200º /sec)
Remote Control : RS-485, RS-422
MPEG4 and MJPEG, Max. 25fps (@VGA)
10/100 Base-T (RJ-45)
Support various network protocol:
HTTP, FTP, SMTP, TCP, UDP, IP, DHCP, DNS, ARP, NTP
PPPoE, DDNS, RTP, RTSP |
|
- Polycarbonate dome cover that is highly resistant to
external shocks and willful acts of vandalism
- Water resistant and dust resistant ( IP66)
- 1/4" Super HAD CCD 410K/470K
- 12X Optical Zoom Lens / 10X Digital Zoom
- Minimum scene illumination : 0.005 Lux
- RS-485 Remote Control
- AC24V / DC12V
- SADT-101WM : Wall-mountable bracket (white) (optional) |
|
| CamPlete camera kits come with everything you need for a complete video camera solution. Indoor kits include camera, lens, and wall mount. Outdoor kits come with camera, lens, wall mount, housing, and ready-to-connect power and video cables. With everything preassembled, installation time is dramatically reduced. The lens is attached, the camera is in the housing, and even the back focus is set at the factory. Ordering is made easier: use one part number instead of several. |
|
| With its integrated color and monochrome camera, 18X auto-focus zoom lens, and built-in receiver, the CyberDome Day-Nite is one of GE Security's most popular high-speed surveillance domes. Its innovative, high-resolution camera features a removable IR cut filter - enabling it to be used for 24-hour surveillance. In daylight, it functions as a color camera sensitive to 0.7 lux. At night, when available light drops below a user defined setting, it automatically removes the IR cut filter - enabling it to function as a monochrome camera with 0.01 lux sensitivity. |
|
| The ultra compact and weatherproof Ball Camera features a gray or black Lexan® housing that can be rotated 350° and tilted 90° during installation. It can be mounted to a ceiling, wall, or over a single gang box. It will withstand temperatures ranging from 14 to 122 °F (-10 to 50 °C). The Ball Camera can be ordered with a black-and-white camera that delivers 580 TV lines of resolution and is sensitive to 0.1 lux, a color camera that delivers 480 TV lines of resolution and is sensitive to 1.0 lux, or a color/monochrome camera that delivers 480 TV lines of resolution. During the day, the color/monochrome camera provides a high-resolution, color image that is sensitive to 1.0 lux. During low-light conditions, the camera will respond to IR illumination from an IR source (such as an IR lamp or LEDs), providing a clear, high-quality image under 0-lux visible light. The Ball Camera is available with a 2.5-, 4-, 6-, 8-, or 12-mm lens. It accepts a 10 to 40 VDC / 18 to 30 VAC input voltage. |
|
