Balmoral septic tanks are designed to provide what is known as primary biological treatment to crude sewage produced in a normal domestic environment. They retains solids and allow them to settle out, where they can be partially broken down by biological action so that only the remaining liquor is left to flow down the outlet drain. This effluent is then sufficiently treated to soak into the ground in an underground distribution system.
Features
-4 products serving 4-22 population
-One piece polyethylene body with high impact resistance
-Wide base for stability and ease of handling and storage
-Sturdy lifting eyes for easy handling and installation
-Inlet pipe swivels through 180° for drain alignment
-Neck can be cut down to suit shallower invert depths
-Reduced excavation depth
-Ventilation pipework allows use of a standard manhole cover
-Internal baffle system is designed for easier desludging
|
|
|
Boralit offers up to 3 types of different septic tanks: classic tanks, all water tanks and tanks with integrated filter. All tanks are made of durable, crack-resistant polyethylene which is light enough to ensure easy, manual installation of the tanks. There are classic tanks (with even surface) to be placed in consolidated sand and reinforced tanks (with special anti-pressure structure) which can be placed in regular sand
|
|
|
|
|
|
PT Series Pressure Tanks
The Brac Systems PT Series pressure tanks are used to support the BRAC Residential and Commercial greywater pumps by providing additional water storage under pressure to meet the total demands of a system if the pump is incapable of supplying the required volumes.
The PT-60L, 80L, 100L and 200L free standing captive air, pressure tanks are all equipped with an EDPM diaphram with a 100psi maximum working pressure (tested to 150psi). Our tanks are manufactured with a tough epoxy-baked finish to ensure there is no air to water contact, for a rust-free operation. The replaceable bladder is made from synthetic rubber which will increase reliability and extend the life span. This bladder design will not permit any water to tank contact which eliminates seeping and waterlogging, and the need for air volume controls.
PT-60L - 60 litre capacity with 20 litres (5.3 US Gal) of draw-down performance equivalent to a 120 litre galvanized tank. 1" NPT connection.
Weight
PT-60L 12.70 kg / 27.90 lbs
Dimensions
PT-60L Height: 58cm (23.2") Diameter: 46cm (18.4")
|
|
The Brac Systems PT Series pressure tanks are used to support the BRAC Residential and Commercial greywater pumps by providing additional water storage under pressure to meet the total demands of a system if the pump is incapable of supplying the required volumes.
The PT-60L, 80L, 100L and 200L free standing captive air, pressure tanks are all equipped with an EDPM diaphram with a 100psi maximum working pressure (tested to 150psi). Our tanks are manufactured with a tough epoxy-baked finish to ensure there is no air to water contact, for a rust-free operation. The replaceable bladder is made from synthetic rubber which will increase reliability and extend the life span. This bladder design will not permit any water to tank contact which eliminates seeping and waterlogging, and the need for air volume controls.
PT-200L - 200 litre capacity with 67 litres (17.6 US Gal) of draw-down performance equivalent to a 455 litre galvanized tank. 1-1/4" NPT connection.
|
|
- Internal baffle design within the tank aids separation and retention of solids, improving the effluent quality thus providing a long life to the soakaway
- Made from composite GRP - strong, light, chemically resistant and watertight
- Press moulded shape provides wide, squat, form which makes the tank easy to install and handle
- Stable base for storage
- Shackles are provided to aid lifting and positioning within the excavation
- All unit volumes are designed in accordance with the recommendations given in BS 6297: 1983
- The new manufacturing process minimises styrene emissions and reduces waste - all the better for our environment
|
|
The septic tanks developed by Premier Tech Environnement are the most resistant and solidly built in their category. The unique structure of these tanks provides better mechanical resistance. The tanks are made of polyethylene, so they are lightweight, easy to transport and can be easily installed on sites that are difficult to access. Their single-piece design makes the tanks water-tight, minimizing odors as well as infiltration and exfiltration risks.
Our septic tanks provide competitive advantages:
- Made of highly resistant polyethylene (ideal for small sites or difficult access)
- Air tight and water tight
- Easy to transport, handle, and install
- Corrosion resistant
|
|
|
Floating and removable material is extracted from domestic wastewater in mechanical septic tanks. This is pure mechanical cleaning, for which you need 500 ltrs of capacity per inhabitant. If you assume a volume of 150 ltrs, the wastewater passes through the system in 3 days. These septic tanks must have a total volume of at least 2000 ltrs. A 2000 ltr system is sufficient for 4 inhabitants, another 500 ltrs, must be incorporated for each additional inhabitant.
|
|
Polymer chamber for underground installation. For connection to domestic building with light wastewater effluent. DN 100 inlet with removable ventilated inlet flow calming device. Outlet DN 100.
Horizontal separation wall for accelerated decomposition of sludge.
|
|
|
Polymer chamber with biological cleansing filter for underground installation. For connection to domestic building with light wastewater effluent. Polymer upper section is vertically adjustable and tiltable up to 5 degrees. With load class B (12.5 ton) cast iron manhole cover based on EN 124. DN 100 inlet with removable ventilated inlet flow calming device. Outlet DN 100 with removable biological cleaning filter.
|
|
| ... products without information |
| |
|
|
|
|
Designed to reduce suspended solids (TSS) discharged in septic tank influent; the SaniTEE® wastewater deflection screen (commonly known as septic tank effluent filter) helps extend the life of drain field, reduce the clogging of the openings in an effluent disposal system and allow flexibility in the use of different types of effluent pumps. Easy to install and maintain, the SaniTEE promotes the natural settling and excludes gas-lifted particles from entering the outlet pipe.
• Single Compartment Tank with Gravity Discharge - Installed into the outlet tee of the tank, its angled slots protects the drain field by retaining the suspended solids inside the tank.
• Dual Compartment Tank with Gravity Discharge - This configuration utilizes the outlet tee of the second compartment, and provides additional solids retention due to flow attenuation and the dual-compartment design.
• Dual Compartment Tank with an effluent pump - This configuration provides primary screening in the first compartment and allows flexibility in the use of different types of effluent pumps.
• Commercial Usage - Utilized at such decentralized commercial properties as restaurants, Laundromats, gas stations, beauty shops or veterinary clinics. When used in these applications, SaniTEE provides many benefits including prolonged drain field life and ease of maintenance.
Additionally, SaniTEE’s patented keyhole weirs help to attenuate surge flows, delivering a consistent flow for further treatment or dispersal. Available in 4”, 8” and 16” model sizes with flow capacities up to 20,000 GPD, multiple SaniTEE wastewater screens can be used for flows higher than 20,000 GPD.
|
|
The PTE Effluent Filter reduces the concentration of suspended matter in the effluent leaving the septic tank. This suspended matter could otherwise cause premature clogging of other system components. The effluent filter is a safety feature that is suitable for all types of septic system installations.
Advantages:
Economical, fast and easy to maintain
Contributes to a longer life for the disposal field
Better environmental protection from better purification quality
Larger filtration surface than conventional effluent filters
Polylok Effluent Filter distributor
Premier Tech Environnement distributes Polylok products in Quebec and Ontario, namely, the following effluent filter models: PL-122 for the residential market and PL-525 and PL-625 for heavier flow applications. For more information on Polylok products, log on to www.Polylok.com.
|
|
