wedi Fundo is already well established with trade professionals
as a reliable and simple means of constructing a waterproof floor-level shower element in wet rooms. These unique tileable units, as well as being eminently practical and reliable, have opened up a whole new world of design possibilities for wet rooms and bathrooms.
For the wedi Fundo Riolito and the wedi Fundo Riofino the shower water drains away through the narrow gap between the cover plate and adjacent tiling.
For both Fundo designs there are three cover plate options made from high quality stainless steel. By adjusting the cover plate height, the Fundo Riolito can be combined with the widest possible range of tiles or natural
stone coverings in an equally wide range of thicknesses from 4.5 mm to 14. 5 mm for Standard and Deluxe channel cover and from 7mm to 20 mm for tileable channel cover.
The Riolito Fundo element includes 50 mm thick side walling to the drainage area to provide a straight joint connection and seal to the adjacent screed in concrete floor applications. These side walls can be easily trimmed off for flush connection of the unit to adjacent walls as required.
• Factory pre-assembly of the drain in the floor element saves time and guarantees a complete seal.
• Big choice of dimensions.
• Anti-siphon trap and strainer are removable and can thus be cleaned easily.
• The prefabricated gradient guarantees a secure drainage.
• The adjusting screws in the drainage channel allow the selection of almost all normal tile thicknesses.
• Three different channel covers are available:
Tileable, Standard and Deluxe versions, all in stainless steel.
|
|
|
|
|
|
Poresta BF 95
95 mm total installation height with 50 mm seal water level in accordance with EN 274.
This system permits an absolutely flat, elegant design of the shower area in your bathroom.
There are no visible borders. The design possibilities offered by this BF 95 is available in all standard dimensions and shapes. Not only design but also the individualism of style is very convincing.
And as a result of optimising the total installation height of the BF 95, even the using of the floor-level shower system in case of low installation heights can be realised now.
Floor-level shower system with low installation height
total installation height of just 95 mm with horizontal drain
standard DN 50 horizontal drain siphon
standard backwater level of 50 mm in accordance with EN 274
pivotable grating frame
adjustable increasing elements for gratings
wheelchair-accessible
drainage capacity 42l/min.
Strong material
BF 95 is a waterproof, coated shower system with an extremely water drains rapidly. In addition to a high level of stability, the pre-fitted, flexible drain system facilitates installation. The grating frame for square and (as an option) circular drain gratings can be adapted to the tile pattern by turning during fitting. Whether it is ceramic, natural stone, mosaic or a similar surface material that is chosen for the floor finish, it is simple to adjust the drain grating frame to match using the appropriate accessory.
|
|
Poresta Slot - water simply disappears
Floor-level shower system featuring shadow gap drainageWith the Poresta® Slot shower system, illbruck has succeeded in creating a totally
new and innovative form of drainage. Discover a new generation in floor-level showers.
The water simply runs away. No grating, no drain - just a barely noticeable shadow gap into which the water disappears. The joint is directly against the
wall and is hardly visible. Taking the showering experience to a new level. The shower area can be fully integrated into the living area. This system enables the size to be adjusted as required. The system's high drainage capacity gives the impression that the water simply trickles away.
|
|
Poresta® BFR universal drain board
One board for all drains
Poresta® BFR universal drain board has developed a shower system for flexible use
of all standard shower drains.
The Poresta® BFR universal drain board can thus be shortened to any desired size.
Outsize solutions are also possible thanks to this simple system. The board can be extended as necessary, enabling any design to be realised in the shower area.
Create the drain of your dreams.
|
|
Floor-level shower system with additional stainless steel designer grating
Limit S shower system from illbruck is a shower drain board The slimline and elegant designer grating is positioned directly against the wall and therefore creates a continuous stainless steel effect along the wall. The illbruck sealing strips provide a safe and reliable complete sealing system for all
|
|
Wet room shower systems with mineral material surface
The Poresta Largo wet room shower system with high quality mineral material surface is equipped with an all-round waste system.
The discrete waste outlet gap ensures speedy draining of the water and lends Poresta Largo an unmistakeable look.
|
|
Poresta BF 70
70 mm total installation height
Poresta BF 70 - the ideal solution for using a floor-level shower system in the
field of renovation. With a total installation height of only 70 mm modern floorlevel shower areas can be created in many old-fashioned bathrooms. Floor-level shower system with minimal installation height
|
|
|
TUB - Shower bases flush with the floor, ready for tiling, in different design variants with matching substrate elements for quick and reliable installation and The building kits for shower design variants.
|
|
It is a fact that in swimming baths, sports centers, hotels, public and industrial sanitary areas as well as in bathroom units in hospitals, homes for the aged and for the disabled, floor-level showers are construction standards or are even obligatory.
The floor-level shower with fixed, tiled splashwalls is increasingly being chosen for private homes instead of the shower tray.
The wedi Fundo is a system for creating floor-level showers, made of the wedi building board as the basis material.
Provided with a sealed horizontal or vertical drain, an additional waterproof coating and the ready-made fall it can be installed easily and securely by the tiler and the builder.
In addition to the large selection of floor units we also provide a wide range of associated shower partitions. There is simply no end to the creative possibilities.
|
|
Shower tray model UNICO in Corian
Thermoformed showering tub with possible installation from floor level.
Length and depth of the shower tray can ba fitted.
|
|
Shower tray model DOGA in Corian
Possible installation from floor level
Strip of Teak Burma
LENGHT AND DEPTH OF THE SHOWER TRAY CAN BE FITTED
|
|
Shower tray model QUADRO in Corian
Thermoformed showering tub
Possible installation from floor level
LENGHT AND DEPTH OF THE SHOWER TRAY CAN BE FITTED
|
|
Perfecting the self-leveling system first on its whirlpool baths, Jacuzzi® now brings Tru-Level™ technology to shower bases. Tru-Level™ shower bases are available in 15 sizes & 11 colors.
|
|
-modern, timeless design
-only 6.5 mm deep
-rectangular or square design
Designer: Phoenix Design
|
|
noble, purist design
covered outlet positioned in centre of one long side
suitable for floor-level installation
made of Kaldewei steel enamel 3.5 mm
|
|
|
This is a hand carved solid stone shower tray. Custom carved to client's specifications. A wide variety of marble and travertine stone types are possible. Floor drain can be centered or offset as needed.
|
|
|
Shower tray in Pietraluce®, dimensions 170 x 90 cm, suitable in the replacement of old bathtubs as it completely covers the resulting empy space, QUEEN model
|
|
|
Custom-made shower tray in Pietraluce®, UNIVERSAL model, dimensions from 800 up to 2000 mm; in any colour.
|
|
|
The TAMESIS acrylic shower tray,in extra high quality, available with or without panels.Incorporates slip-resistant surface
|
|
|
Strado is the most recent series of acrylic shower trays with great dimension, with four options of length 120|140|160|170 these shower trays possess two accessories, a seat and a platform with watery isolating finishing that allows them to be in contact with the water without damaging and are available in the colors wenge or teak. Of right and simple lines this series confers to your shower space the comfort ally to modern design.
|
|
-a classic among shower trays
-modern, clear design
-available in rectangular or square design
Designer: Phoenix Design
|
|
The LOIRA shower tray is made heavy gauge enamelled steel. Available in three versions including extra-flat.
Optional extras:
Slip-resistant surface.
Sound-proofing pads
|
|
The DUERO shower tray is made in heavy gauge enamelled steel. Minimalist corner design. Maximum guarantee.
Optional extras:
Special slip-resitant surface.
Sound-proofing pads.
Chrome waste valve
|
|
The RHONE shower tray is made of heavy gauge enamelled steel. Available in three versions incluiding extra-flat.
Optional extras:
Slip-resistant surface.
Sound-proofing pads.
|
|
|
Water Drop enhances the properties of ceramic, it is characterised by its original minimal design and its reduced height and proposed in different sizes. It can be installed on or flush with the floor: all elements that make this object easily adaptable to different necessities.
|
|
ELEMENT SUBGRADE LEVEL
For a exquisite optics and a reliable function 10 mm strong safety glass and a circulating Wasserrinne stand. Whether ground-same or classical installation prepares the ground for a completely new aesthetics into a landing, ELEMENT SUBGRADE LEVEL.
ELEMENT SUBGRADE LEVEL offers still more. The new showering ground can be combined freely. Together with rear wall and side parts you arrange a shower completely from glass.
I-Tüpfelchen: Paints and motives of your choice. Do they think of a waterfall? Would you like to shower in the poppy field? Do you love it classically in black-and-white in pure diagram, how opposite shown? We print the glass ground and the glass rear wall on individually. Photo or digital data is sufficient.
|
|
|
Flaminia renovates the shower area. Tatami, named after the Japanese flooring concept, is a modular system of ceramic elements with a non slip surface that also serves as a foot massage. Further to the basic compositions of 2,3,4,and 5 bricks, it is also possible to create custom designed areas.
|
|
Shower tray in travertino
Footrest shower in teak massello
|
|
Whatever the shape or size needed – deep, shallow or super shallow, round, quarter-circle, oblong, square or free form – Hoesch has got the right shower tray for you. All shower trays in the Hoesch range, one of the most comprehensive on the market, have a totally non-porous, acrylic finish, making them non-slip and easy-care. Why not try one out?
|
|
|
|
