The ultimate aesthetic adjustable structural cable tendon.
Rated B.L.:
Up to 285kN / 29060kg / 64070lb
Cable Diameters:
4mm to 22mm
Specific Features
- A minimalist, sleek and compact cable solution for static architectural applications.
- Ultimate aesthetics in stainless steel.
- Fully adjustable telescoping end fittings.
- Fully concealed threads.
- Moderate adjustment.
-A simple and effective adjustable cable.
|
|
|
|
|
|
An attractive jaw (clevis) type cable system in stainless and carbon steel offering increased level adjustment.
Rated B.L.:
GS - Up to 1189kN / 121240kg / 267290lb
SS - Up to 945kN / 96420kg / 212330lb
Cable Diameters:
Type 1: 3mm to 10mm stainless steel.
Type 2: 12mm to 26mm stainless steel.
Type 3: 28.6mm to 36.3mm stainless steel.8.1mm to 36.3mm galfan coated carbon steel.
Specific Features:
- Fully adjustable cables offering increased adjustment with the inclusion of a turnbuckle one end.
- Type 1 and Type 2 cables have turnbuckles with moving parts of dissimilar metals to avoid thread seizure under load.
- Type 1 and 2 cable end fittings have articulating (toggle) jaw ends offering adjustment in two planes to accommodate some cleat misalignment, and relieve stresses caused by dynamic and cyclical loads.
- Type 3 cables have turnbuckles designed specifically for large diameter applications and are manufactured to nominated design loads.
- All ends offer simple and easy connection with clevis and split pins.
- All turnbuckles offer lock nuts to positively lock adjustment.
- A robust structural cable offering maximum adjustment.
- Can accommodate moderate dynamic loads.
- Type 1 and 2 cables can accommodate misalignment of the cleats of +/- 10 degrees.
|
|
|
Range wide of accessories inox for implantation and tensionamento metallic cables for different employs, accessories to mechanical implantation.
|
|
|
A carefully researched construction allowing for numerous variations, horizontal angles, in rakes, curves and bends. Metaline responds perfectly to pre-cast stairs and complex structures. Made for private and public use and combining finishes with horizontal midrails, glass, mesh and perforated panel inserts and fully conforming to British Standards.
|
|
|
mounting double flat with predisposition for 3-5-8 cable in acciao inox diam.5mm cross-sectional
|
|
A simple, clean and economical cable
Lengths/Span:
Typically suits straight runs up to
ABS2 Type A - 10m (32’) maximum length.
ABS2 Type B - 5m (16’) maximum length.
Cable Diameters:
3mm
4mm
5mm
Specific Features
- An in-line system of minimal visual impact with no bulky turnbuckles to impede views.
- Neat and simple architectural connections for the ultimate clean look.
- Easy tensioning from the outside of the post allows fast installation and minimal time on site.
- The system is perfect for both vertical and horizontal configurations.
- Quality Grade 316 stainless steel construction suitable for harsh environments and long service life.
|
|
The versatile cable with a bold technical style
Lengths/Span:
Typically suits straight runs up to
ABS2 Type A - 10m (32’) maximum length.
ABS2 Type B - 5m (16’) maximum length.
Cable Diameters:
3mm
4mm
5mm
Specific Features
- ABS2 utilizes the unique Microloc adjuster, a bold contemporary interpretation of the dependable and reliable traditional turnbuckle.
- The articulated fork end and wide range of mating connections are perfect for both stair and horizontal balustrade/railing applications.
- Versatile connection options to suit timber or metal posts.
- Simply tensioned with a standard spanner or wrench – no special tools.
- Unique tamper resistant “press” pin option is available to minimise theft or damage. (below)
- Quality Grade 316 stainless steel construction for harsh environments and long service life.
|
|
Metallic fabrics, you enmesh flexible or rigid with multitude of forms and designs that allow to cover great outer surfaces, to create inner virtual spaces or simply to generate illusions visual combining light and color.
The stainless steel fabrics are very versatile as much in their applications as in their characteristics, with a great variety of models that can make in the measures that the project demands and use the more appropriate systems of anchorage for each application.
Outer closings of great spaces that combine esthetic and functionality in a same material. Applications for interiors, panelado of walls, division of spaces or subtle light filters.
|
|
Kit of customized assembly composed of posts with tensions, handrails and cable, with the following options to define by the client:
- Type of fixation: Lateral ground or.
- Type of tension: Several references.
- Thickness of the cable: 4 or 5mm.
- Length overall handrail.
- Completions of the handrail: Cork (several types) or anchorage to wall.
- Quality Steel: AISI 304 or AISI 316 (next to coasts or pools).
- Finished Steel: Satin brightness or.
|
|
|
|
