SPACE REFLEX® foil SR 03 is composed by one sheet of aluminium on one side, with one layer of air bubbles.
|
|
|
SPACE REFLEX® foil SR 01 DB is composed by one sheet of aluminium on one side, with two layers of stanched air bubbles, hermetically closed, on the interior.
|
|
|
SPACE REFLEX® foil SR 01 F5 is composed by one sheets of aluminium on one side, with one layer of stanched air bubbles, hermetically closed, on the interior and one layer of foam on the other side.
|
|
|
SPACE REFLEX® foil SR 01 is composed by aluminium SR on one of the sides, with one layer of stanched air bubbles, hermetically closed, in the interior, and one layer of polyethylene sheet on the other side.
|
|
|
SPACE REFLEX® foil SR 41 DB is composed by two sheets of aluminium on both sides, with two layers of stanched air bubbles, hermetically closed, on the interior.
|
|
|
SPACE REFLEX® foil SR 41 is composed by two sheets of aluminium on both sides, with one layer of stanched air bubbles, hermetically closed, on the interior.
|
|
|
SPACE REFLEX® foil SR 42 is composed by aluminium SR on both sides, with one layer of stanched air bubbles, hermetically closed, in the interior.
|
|
|
SPACE REFLEX® foil SR 42 DB is composed by two sheets of aluminium on both sides, with two layers of stanched air bubbles, hermetically closed, on the interior.
|
|
TRISPACE HABITAT® is o new concept of multi-layer wadding/foil insulotlon motetlals that combines TRISPACE® wadding (fibre proportions of 1% and less), 12-micron foils (aliminium sheets) and outer loyers mode of reinfotced aluminium. This concept achieves optimal heat reflection by returning the heat that is generated inside the house by the heating system during the winter and by expelling the heat in the summer in order to avoid any sudden température changes.
PEG's long-standing involvement with heat-insulating wadding and the company's flexibility. both in terms of means of production and staff that are skilled in the entire production process of insulation products, means that its four TRISPACE HABITAT® products offer the best value for money on the construction and DIY markets.
A compromise between thin and tradîtional insulating materiols
|
|
Components/
2 armed polyester films, metallized
6 waddings Dacron® Hollofil®
100 gr/m2
4 metallized polyester films 12u IF Thickness/approximately 60 mm m Dimensions/
10 m X 1,50 m, are 15 m2 m Poids/approximately 18 kg m Piquage/straight lines,
spacing 30 cm
Thermal comfort summer/winter
Not irritant, nontoxic
Easy to implement
Inspired of the peeling of the polar bear
Only insulation multi-layer with garnishing
Dacron® Hollofil®
Hollow fiber with 4 channels, imprisons 20%
of air in more than one traditional fiber for one
better insulation
|
|
|
Felt out of glass wool covered with an aluminum vapor barrier armed with a grill of glass with two side strips of fastening.
|
|
|
Heat insulator with layer out of aluminum reflecting heat usable behind heating or like insulation enters a heat source and a cold element.
|
|
The UltraTouch Natural Cotton Radiant Barrier Thermal/Acoustic Insulation is an extremely versatile and superior performing product that can be used in automobiles, trucks, buses, RV's, boats, aircraft, residential and commercial building.
The UltraTouch Natural Cotton Radiant Barrier brings fire, fungi, and corrosive resistance to an insulation product that is formaldehyde and resin-free.
The UltraTouch Natural Cotton Radiant Barrier´s natural fibers provide a non-itch padding that is easy to handle and install.
The pure aluminum barrier used for The UltraTouch Natural Cotton Radiant Barrier provides exceptional protection from air currents, vapors, moisture, and radiant heat.
Use The UltraTouch Natural Cotton Radiant Barrier as a: Radiant Heat Barrier, Acoustic Sound Barrier, Airflow Barrier, Thermal Heat Barrier.
|
|
|
The complex is made of two 3 mm layers of extruded polyethylene in 35 kg density. Grey to the bottom and white to the top. The top layer is laminated to a layer of HDPE which carries the trade mark ACOUSTICREFLEX®. Using the 100 mm overlap on the top sheet it is overlaid (shingled) in use, eliminating cold spots. Thus it is in total minimum 6 mm and max. 9 mm on the overlap. The material is inert and moisture free, has a high resistance to chemicals and acts as a vapour barrier.
|
|
|
ArmaSound Floor is a lightweight, closed cell elastomeric foam that has been designed to act as an under screed resilient layer. Resilient layers acoustically isolate the concrete subfloor from the surface screed which is laid on top.
|
|
|
Class O Armaflex is the flexible, closed cell, elastomeric, nitrile rubber insulation that offers reliable protection against condensation and effectively prevents energy loss.
|
|
» Made with Microban® antimicrobial product protection
» Faster for tanks, vessels
» The "IAQ" InsulationTM
» Dust free, fiber free, closed cell
|
|
Made with Microban® antimicrobial product protection
» Faster for tanks, vessels
» The "IAQ" InsulationTM
» Dust free, fiber free, closed cell
|
|
» The IAQ InsulationTM for air ducts
» Made with MICROBAN® antimicrobial protection: EPA Registered for ductwork, including hospitals
» Reduces HVAC noise
|
|
Multifoil M15® is manufactured from numerous layers of high strength polyester, metallised polyester film and polyester wadding.
Multifoil M15® seals your roof against all the elements whilst retaining ventilation, it prevents your roof space over-heating in summer, whilst retaining warmth in winter. The product is welded to ensure no perforations if all joints are sealed Multifoil M15® acts a vapour control barrier in one layer.
Main Benefits
-Prevents roof over-heating in summer.
-Retains warmth in winter.
-Welded joints.
-Quality foil, guaranteed not to oxidise.
-Space saving rolls, ease of Installation.
-Flexible, can fit the most difficult of roofs.
-Contains no toxic products.
-Clean, does not cause dust.
-Does not incur any allergies.
-High strength polyester, reinforced metallised polyester film and polyester wadding.
|
|
Domaines d'applications
Isolation Toiture et Murale
Composition : 17 composants
-2 films thermo réflecteurs armés extérieurs
-2 couches de laine de lin
-5 films thermo réfl ecteurs intercalaires
-4 couches de mousse
-2 couches de ouate
-2 couches de non tissé
Epaisseur : 40 mm
Conditionnement : Rouleau de 1,50m x 10m
|
|
Thin thermoreflective insulator
Technical description
Areas of application :
Quatro® M1 M1 is specially adapted to roof and wall
insulation:
-convertible attics
-walls and partition walls
-chalets
-modular constructions
-industrial and farm buildings...
Composition :
Quatro® M1 is a top-of-the-range complex combining thermal and acoustic insulation.
The reflective surface (99% pure aluminium) is covered with a protective varnish that prevents any oxidation phenomenon.
The heat and acoustic insulating surface is obtained by 4 layers of fire-retardant polyethylene bubbles with trapped dry-air bubbles.
This multilayer insulator encloses 3 additional air spaces between the 4 layers of bubbles, thus ensuring extremely effective insulation.
Assembly is done by thermal welding
Thickness: 14mm
Standard packaging:1.25 x 25m
Aluminium: 2 x 30μm
Fire-resistant polyethylene: 4 x 160μm
Total weight/m2: 732g
|
|
Technical Insulation consists of specially developed insulation products for use in Heating Ventilation & Air-conditioning (HVAC) applications and industrial processes used in power stations, petrochemical plants, refineries, food and drink production facilities. These applications require a winning combination of thermal, acoustic and fire protection insulation.
Knauf Insulation high-tech glass mineral wool and rock mineral wool fits your requirements with a high degree of flexibility. Our high-performance insulation products offer the opportunity to gain process control as well as energy loss reduction, fire protection and acoustic sound reduction.
At Knauf Insulation, we provide a wide range of HVAC products for the mechanical engineer and contractor.
Main Technical Insulation applications:
Industrial Process Plant (Power & Petrochemical Plants)
Heating, Ventilation and Air-conditioning (HVAC)
Machine Insulation
|
|
CertainTeed SoftTouch™ Duct Wrap Insulation offers outstanding thermal properties that reduce unwanted heat loss or gain and condensation during system operation. SoftTouch duct wrap is GREENGUARD® Certified as low emitting.
CertainTeed SoftTouch duct wrap products are used to insulate rectangular and round heating, ventilating and air conditioning ductwork.
|
|
L%u2019ATI 500® est l'isolant multicouche bullé le plus élaboré de sa gamme. La combinaison du laminage pleine surface et de l'assemblage gaine fait de ce produit la référence du marché.
En toutes saisons, l'ATI 500® assure une isolation constante et performante, avec, à la clef, des économies d'énergie (chauffage et climatisation). Sa faible épaisseur (20 mm) permet d'optimiser la surface habitable (gain de plus de 10%).
|
|
|
|
