SHR-5162- Video recording up to 120/100ips and 4 channel audio recording
- Recording and network transmission via each codec by adopting dual codec.
- Exclusive video processor
: image quality improved by more than 30% compared to existing products.
- Various backup through USB 2.0
: USB memory, external HDD,
external CD-RW (SHR-5042), DVD-RW (SHR-5082/5162).
- Various video outputs supported.
- Simultaneous VGA and composite output.
- Watermark for preventing video alteration.
- Remote monitoring and control through network
: Ethernet, cable network, xDSL.
- Convenient IR remote controller and mouse.
(Mouse is only available for SHR-504x)
- Smooth backup by using built-in DVD-RW (SHR-5082/5162).
- Convenient user interface : Event, Date/Time, Go to First
/Last, Backup Search and Calendar functions. |
|
-Records video from up to eight network cameras with megapixel resolution
-Easy to install, use and manage
-Enables simultaneous recording and remote access to recorded video as well as live viewing
-Records up to 100 frames per second at VGA (640x480 pixels) or 4CIF (704x480 NTSC, 704x576 PAL) |
|
- 8Channel 240/200 ips (SHR-4081), 16Ch 360/300 ips (SHR-4160)
video recording and 8-Channel audio recording
- Spot output monitoring
(full-screen monitoring function of a specific channel)
- Monitoring through general monitor, or PC monitor
- Convenient search through a variety of search methods,
and by jog & shuttle
: Event, Date/Time, Go to First/Last, Backup Search functions
- Build an optimal monitoring environment
by selecting a variety of record resolutions
: CIF, Half D1, D1
- Motion detection (zone setting)
- Watermark to prevent video alteration
- Remote monitoring and remote control through the network
: Ethernet, Cable Network and xDSL support
- Expandable up to 1 TB (250GBx4)
- Portable CD and DVD R/W can be attached (using USB)
- A variety of backup interfaces
: USB 2.0/IEEE1394(SHR-4081/4160) |
|
- 4-channel 120 ips real-time video recording
and 4-channel audio recording (SHR-204X)
- 8/16-channel 120 ips real-time video recording
and 4-channel audio recording (SHR-208X/216X)
- Various backup through USB
: USB memory, portable HDD, portable CD-RW and DVD-R
(SHR-2XX2 Series do not support portable CD-RW/DVD-RW)
- Spot output monitoring (full-screen monitoring function
for a specific channel, auto sequence)
- Easy search, through access to a range of search methods
: Event, Date/Time, Go to First
/Last, Backup Search and Calendar functions
- Motion detection (zone setting)
- Watermark to prevent video alteration
- Alarm message sent to registered users (CallBack)
- Remote monitoring and control through the network
: Ethernet, Cable Network and XDSL support
- Remote control through the IR remote controller
(SHR-208X/216X)
- Compact size overcomes installation space limitations
(SHR-2040)
- Possible to expand up to 1 TB (250GBX4) (SHR-2080/2160)
- Supporting efficient backup by incorporating
a built-in CD-RW unit (SHR-2XX2) |
|
- Recording at a maximum speed of 480/400 ips
(SPR-7416, 320x240 standard)
- Various resolutions can be set for monitoring or recording
(640x480, 640x240, 320x240, 160x120)
- Recording compression ratio: 2.5KB/image(320x240)
- Hardware watchdog: Auto-recovery system when the system is
operating abnormally
- Video correction circuit: 4 phases, according to the distance
between the DVR and the external monitor Settings
: 100m, 200m, 300m or 400m
- Motion detection
- Alarm output
- Image quality adjustment (sharp, soft and revised),
screen enlargement and reduction
- Alert sound generated when a motion is detected by a camera
- 1-channel simultaneous video/audio recording and searching
- Pan/tilt/zoom of the camera can be controlled
(built-in zoom cameras only)
- Emergency screen automatically sent to the center set in emergency situations
- Auto password-check: Prevents arbitrary manipulation
by outside hackers
when communicating remotely to change a system setting
- Remote DVR control through the network
- Video checking and real-time monitoring through the network
from a remote location
- 16 DVRs can be simultaneously managed from a client viewer
- Watermark
- Built-in virus protection
- RoHS |
|
ARTICLE CODE
391490
CATEGORY
Communication: equipment for video door entry, telephony and signalling systems > CCTV
DESCRIPTION
CCTV - digital video recorder - hard disk = 40GB - 230V a.c.
TECHNICAL DETAILS
Rated voltage 230 V a.c. 50-60 Hz.V
Type of system TVCC
Height 90mm
Width 430mm
Depth 374mm |
|
