MAIN CHARACTERTISTICS
Insulation class: II,I.
Energy class: A++
Protection Degree: IP66 | IK08
LED Modules: removable / replaceable optical unit.
Mounting: mounting with adjustable integrated flange.
Control gear box: integrated. Removable.
Available dimming options:
F - Fixed power not dimmable;
DA - Custom DA profile;
DB - Dual power dimming with pilot wire;
DALI - DALI digital dimming interface;
PLM - Power line single point communication system;
WL - Wireless single point communication system.
OPTICAL SYSTEM
ASP/ASC: multi-focal asymmetric optic with adjustable emission.
STU: asymmetrical optic for street lighting (urban).
STE: asymmetrical optic for street lighting (suburban).
STW: asymmetrical optic for wide roads and wet asphalts lighting.
S05: asymmetrical optic for urban and street lighting.
Colour temperature: 4000K (3000K, 5700K optional), CRI ≥ 70
Photobiological safety class: EXEMPT GROUP
LED source efficiency: 138 lm/W @ 700mA, Tj=85°C, 4000K
MATERIALS
Fixing: galvanized and painted steel.
Body, heat-sink and control gear box: die-cast aluminium UNI EN1706 with low copper content.
Powder painted.
