Tunnel lighting GALILEO 1 EB

tunnel lighting
tunnel lighting
tunnel lighting
tunnel lighting
tunnel lighting
tunnel lighting
tunnel lighting
Add to favorites
Compare this product


Description

APPLICATION Floodlighting and architectural LED lighting luminaire. MECHANICAL CHARACTERISTICS Fixing in stainless steel AISI 304 (AISI 316L optional) with plastic spacers to avoid galvanic corrosion. Body and heat-sink in die-cast aluminium UNI EN1706 with low copper content. Powder painted. Gasket in polyurethane. Mounting with adjustable integrated flange (see available flanges section) Screen: flat tempered glass 4mm thickness. High transparency. Metallic cable gland M20x1,5 – IP68 Protection degree IP66 | IK08 Operating temperature: - 40°C + 50°C (525mA) - 40°C / +35°C (700mA) ELECTRICAL CHARACTERISTICS Insulation class: I, II. Power supply: 220-240V - 50/60Hz. LED current: 525mA | 700mA Power factor: > 0.9 (at full load). Surge protection: Pulse withstand CL. I: ≥ 10kV CM/DM Pulse withstand CL. II: ≥ 8kV CM/DM. LED source lifetime (Tq=25°C, 700mA): ≥100.000hr L90B10 ≥100.000hr L90, TM-21 Dimming options: F: Fixed power not dimmable. DB: Dual Power with control wire. DALI: Digital dimming interface DALI. FLC: Constant light flux.

Catalogs
