Panel cladding LARCORE® A2
compositealuminumsmooth

panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
panel cladding
Add to favorites
Compare this product


Characteristics

Configuration
panel
Material
composite, aluminum
Finish
smooth, matte
Appearance
metal look
Technical characteristics
insulated, incombustible
Other characteristics
decorative
Color
brown, gray, white, black, beige, red, orange, silver-colored, blue, green, multi-color, yellow
Length

Min.: 2,000 mm
(79 in)

Max.: 14,000 mm
(551 in)

Height

Min.: 1,000 mm
(39 in)

Max.: 2,000 mm
(79 in)

Thickness

6 mm, 8 mm, 10 mm, 14 mm
(0.24 in, 0.31 in, 0.39 in, 0.55 in)

Description

larcore® A2 is supplied in thicknesses of 6 mm and 14 mm (both panels), with specific installation systems, and in other thicknesses for installation with universal systems such as rivets, screws or adhesive. larcore A2 6 mm Metal panel with aluminium honeycomb core for architectural façades, false ceilings, sun shades and slats. Made up of aluminium sheets of 0.7 mm on the exterior face and 0.5 mm on the interior, both in aluminium alloy 5005 EN 573-3 joined by an aluminium honeycomb core. Hidetech Installation System Installation system using cassettes developed by Alucoil® for the 6 mm thick larcore® A2 panel. The perfect solution for architectural façades, false ceilings, sun shading and slats. Supplied with 2 coating options: 1. Quality dual-layer PVDF (Kynar or Kylar as the main brands) with the first coat with a nominal thickness of 31µ. An innovative solution that reduces the substructure on the façade by 30%, but that can be executed with the traditional tools of the sector. Probably the lightest option despite its rigidity, non-combustible and with the best flatness on the market. NEW fluorlac® 2. fluorlac® brand of LUMIFLON™ FEVE paint developed by Alucoil® available in the larcore® A2 on range from 75 m², in any colour, in matte, satin and high gloss finishes in just 2-3 weeks. larcore A2 14 mm Metal panel with aluminium honeycomb core for architectural façades, false ceilings, sun shades and slats. Made up of aluminium sheets of 1 mm on the exterior face in aluminium alloy 5005 EN 573-3 and 1 mm on the interior face in aluminium alloy 5754 EN 573-3 joined by an aluminium honeycomb core.
