Material: Luminaire housing in cast aluminium.
Body made from extruded aluminium.
Installation: Fastened by bolts (4 x M12) in a solid base or on a mounting for 108 foundation or for in-situ casting. Ordered separately, see accessories.
Connection: Cable (max Ø13 mm) connected to luminaire housing
(terminal block 5x2.5 mm²). Feed through possible.
Strain relief for cable in luminaire housing.
Standard colour: Aluminium-grey ~ RAL9006 textured, Anthracite-grey ~ RAL9023 textured or Ruby red RAL3003 textured.
Other colours available on request.
Glare shield: Clear PC.
Light scattering: Asymmetric.
Light source: Incl. LED light source, colour temperature 3000K.
Colour rendering CRI 85. Chromaticity tolerance 3 SDCM.
Service life: L70 B50 50 000h.
Other: iK code 07.
