DIN rail actuator 0-10V

The MyHOME_Up Temperature regulation system can make heating and cooling systems with many functions so that the temperature of each room can be selected depending on the room’s function and the time of day when it is used. You can also select the rooms which you do not want to heat because they are not used. Activating the system also takes into consideration the heat produced by the sun and whether any windows are open (optional function). Thanks to the zone temperature regulation function the building gains an energy class and users save on the bill. Small-scale systems, made only with probes with display and therefore without the help of the thermoregulation unit, can be managed locally and remotely via the specific MyHOME_Up app for Android and iOS Smartphones. Range System composition The MyHOME_Up temperature control system consists of the following devices: Probes with and without display Actuators Power supply We can create 2 types of systems with the possibility of managing up to 99 zones: By installing the display probes used as a zone thermostat, and with probes without display and related actuators. With the MyHOME_Up application, the system is started up and the relative operation of the individual devices is checked. It is also possible to define heating activation programs with customized profiles. By installing the MyHomeServer1 gateway, in addition to the various probes and actuators, the system can also be managed by the HOMETOUCH touch screen and by Smartphone with the MyHOME_Up App. Actuator with 2 output 0-10V Actuator with 2 x 0-10 Volt outputs for the control of 0-10 proportional valves - SCS bus connection, 2 DIN modules
