Article No.
111 1102 51 100 / 111 1102 21 100 (24V)
Temperature range
5 … 30 °C
Contact
1 break contact
Operating voltage
230 V AC 50/60 Hz
Switching current
AC 10 mA … 10(4) A; DC 100 W
Temperature set-back (TA)
~ 5 K
Hysteresis
~ 0,5 K
Protection class of housing
IP 30 / insulated
Dimensions
75 x 75 x 25,5 mm
• Attractive design
• Bimetal technology with thermal feedback and high precision
• Surface mounting or directly on a conduit box with vertical fixing
holes or on a DIN rail with a snap-on clip
• Clear terminal arrangement and ample terminal space for quick and
easy installation
• Housing color: pure white (similar to RAL 9010)
• Range limitation inside setting knob
• Mountable on adapter frame ARA 1E
(accessories see pages 71–72)
