Sliding shutter NATURE-MAX15

woodenfor facades

Surface Solid wood slat, planed Fine structure matt (standard), silk gloss, matt Powder-coated 200 °C before assembly Type of wood Siberian larch Colours Colours available on request and in accordance with order placement once a sample has been produced and approved Pretreatment Untreated; Glazed slats on request Notes A support profi le is required for widths greater than 801 mm When the height exceeds 2200 mm, the slats are screwed to the inside of the frame to act as a horizontal cross-panel The considerable weight must be taken into consideration when preparing assembly Min./Max. dimensions Width: 550 to 1600 mm Height: 800 to 3000 mm Min./Max. infeed Approx. 70,0 – 80,0mm Weight Approx. 16 kg/m² Frame profi le 48 × 48 mm extruded aluminium hollow chamber profi le Slat profi le 60 × 22 mm solid wood slat Slat carrier profi le 32 × 11 mm extruded aluminium profi le Support profi le 20 × 5 mm extruded aluminium hollow chamber profi le Corner connections Glued-in aluminium bracket with visible notch in the outer frame Options Electric drive
