Surface Fine structure matt (standard), silk gloss, matt
Powder-coated 200 °C before assembly
Colours RAL Classic, RAL Design, NCS, VSR
Finishes Wood, stone, rust
Pretreatment Ocean Line Plus possible
Notes Drain holes at bottom of frame
Slats are exchangeable
Min./Max. dimensions Width: 550 to 2200 mm
Height: 800 to 3000 mm
Min./Max. infeed min. 40,0 mm, mean value 50,0mm
Inclination angle 35°
Weight Approx. 11 kg/m²
Frame profi le 48 × 48 mm extruded aluminium hollow chamber profi le
Slat profi le 52 × 11 mm extruded aluminium hollow chamber profi le
Slat carrier profi le 32 × 11 mm extruded aluminium profi le
Horizontal cross-panel profi le 60 × 32 mm extruded aluminium hollow chamber profi le
Corner connections Glued-in aluminium bracket with visible notch in the outer frame
Options Vertical cross-panel | Horizontal cross-panel | Electric drive
