When it is really important not to mar the aesthetic design of a room with technical elements, the mini presence and motion detectors are the perfect solution. Their tiny housings and extremely low installation heights mean that they retreat unobtrusively into the background, while nevertheless keeping a close eye on everything thanks to their high-quality sensor technology. They are available for all common operating technologies and consistently impress clients due to the ease of use.
SHORTFACTS
Installation typeRecessed mounting
Installation positionCeiling
Protection typeIP65
DimensionsHeight/Depth 47 mm, Ø 25 mm
Power consumption0.2 W
Detection angle360°
Detection range diagonallyØ 6 m
field of detectionup to 28 m²
Light measurementmixed light
Level of brightness5 - 2000 lx
Warranty5 years
TECHNICAL DATA
GENERAL
Special product featuresSimple programming using remote control with "blue mode" technology
ConformityCE , RoHS , WEEE
MOUNTING
Installation typeRecessed mounting
Installation positionCeiling
Installation dimensionInstallation depth: 36 mm, Ø 20 mm
Connection1.5 mm²
HOUSING
DimensionsHeight/Depth 47 mm, Ø 25 mm
Weight36 g
MaterialUV-stabilised PE
Protection typeIP65
Permissible ambient temperature-25 °C...+50 °C
Relative humidity5 - 93 %, non-condensing
ColourOpal matt
ELECTRICAL VERSION
Protection classII
Nominal voltage230 V / 50 Hz
Supply line20 cm, 3 x 0.75 single conductor
Power consumption0.2 W
In-rush current30 A / 20 ms
