The Orchidea pocket door kit for brick wall is manufactured from galvanised steel panels incorporating «top quality easy-film passivation», which have been roll-formed with dovetail corrugations to provide maximum rigidity and thus ensure a perfect structure for plastering.
A 50×100 wire mesh fixed to the outside panel of the cassette enables the plaster to bond to the cassette ensuring a uniformly finished wall.
Finished wall thickness 90 – 105 – 125 – 145 mm
Maximum door weight 120 kg
Width (finished door opening) 120-140-160-180-200-220-240 cm
Height (finished door opening) 200/210 cm
