Louvred JK Technic gratings with inclined blades are used for façades to provide a visual screen, a brise-soleil effect or a privacy screen, as well as to form a wall that counteracts any impressions of emptiness.
Louvred JK Technic grating is manufactured according to a precise load table. The dimensions of the bearing bars (BB) are important because they determine the load bearing capacity of the grating.
MESH CENTRE DISTANCES
These are decided based on standards and load capacity. For louvred grating, mesh centre distances for the BB and TB are typically in multiples of 11.11. JK Technic has a range of louvred gratings with different mesh available:
100 x 30 - 60 x 30 - 30 x 30.
Other options are available on request.
DIMENSIONS
Maximum dimensions: 2,500 x 2,000 mm.
For optimal grating quality, we advise you not to exceed a height/length ratio of 1.5 m2.
BEARING BARS
Standard thickness: from 2 to 3 mm.
MATERIALS
S235JR steel as per EN 10025 standards.
304 (1.4301) or 316Ti (1.4571) stainless steel.
AlMg3 aluminium.
