Simply let your system disappear underground. The premium underfloor systems from KLAUS Multiparking no longer move upwards but move one, two or three levels downward. The upper platform when lowered is flush with the ground. Above ground, you gain a car-free area, which you can now design according to your own ideas – for an increased value for your real estate.
The type MultiBase U20 is traversable and can thus be used in courtyards,
front gardens and green areas.
They combine highest comfort with optimum use of space.
The modern systems set new technological standards and
offer space for up to four cars.
This way, parking space for cars can be realized
where no space was available so far, even in inner courtyards or confined access areas. A true improvement in everyday quality of life.
SPECIFICATION
Single platforms U20 (EB) for 2 vehicles
Pit depth of standard type: 425 / 430 cm
Vehicle measurement: Heights from 165 and / or 200 cm, lengths from 500 to 520 cm
Usable platform width for standard type: 230 cm, optionally up to max. 270 cm
Standard design: 2.000 kg per parking space, optional max. 2.600 kg EB
Horizontal access to all parking levels
Flush-mounted and traversable, controlled rainwater drainage
Freely configurable surface area: cassette-construction lid, which can be adapted
to surroundings based on customer request (e.g. stone lining, turf)
Platform surface: EasyWalk, optional AluLongLife or StandardGrip
independent parking
FIELD OF APPLICATION
Residential and commercial buildings, single and semi-detached houses, office buildings, underground parking lot, hotels, surrounding property, outdoor installation, installation in backyards
