Sectional industrial door ELEMENT-R

steelsemi-glazed

Glazed panels in anti-shock PMMA (UV resistant) allow for excellent transmission of light and are very resistant to shocks. Dimensions Bay width: From 1,500 to 6,000 mm Bay Height: from 1,560 to 5,500 mm according to configuration All other dimensions on request Panel insulation Up to U = 2.3 W/m²K Panel height 500 mm or 610 mm Glazed panel White lacquered aluminium frame Three types of infill Combinations Possibility of combining foamed and glazed panels Combinations Class 4 up to 5,000 mm wide Class 5 upon request Locking Lateral locking, lockable as an option Operation Manual (according to dimensions) Chain hoist Motorised
