Laminated glass panel

patternedtranslucentfor interior

Maximum panel size: 2150mm x 5000mm Thicknesses: This will be determined by the size of the panel and its application. Type of glass: Most laminated glass is specified in clear float glass as this is less expensive than low iron glass. However, for certain colours like yellow, orange and red and for the lighter coloured fabric laminates, the green tint in clear float glass effects the clarity of the colour. In this situation, we advise that low iron glass is specified. Cut-outs/notches/holes: Laminated glass can be processed as any other standard glazing, however, the glass will have to be toughened if cut-outs, notches or holes are required. Edge detail: Laminated glass can be processed as any other standard glazing: however, the glass will have to be toughened if cut-outs, notches or holes are required. Safety: Laminated panels conform to BS6206. Fabric laminates: We can laminate a wide variety of fabrics. The fabric is sandwiched between layers of clear PVB/EVA. to add texture, colour and pattern to laminated glass. We have a range of standard fabric
