Metal ceiling strip
LT CLOSED GAP
METALSCREEN
False ceilings system composed with linear stripes METALSCREEN "LT CLOSED GAP" width mm.100 closed gap (thickness and colour choosed by the consultant) aluminium prepainted thickness mm.0,5-0,6. The "LT CLOSED GAP" stripes will be installed on supporting main carrier Art. 63 galvanized hot dipped steel or painted black thickness mm.0,6 and suspended with rigid steel galvanized hangers Art. 100 with metal snap suspension Art. 23/D, finished with perimetrical wall angle frames "L" section Art. RA with connection joint. To obtain the best soundproofing result the "LT CLOSED GAP" stripes must be perforated with holes diameter Ø mm.3 or Ø mm.2 on the total surface with acoustical "TNT" non vowen textile thermal applied on the back of each stripe.
