ceiling air diffuser / square
KTF MP3

Add to MyArchiExpo favorites
ceiling air diffuser / square ceiling air diffuser / square - KTF
{{requestButtons}}

Characteristics

  • Installation:

    ceiling

  • Shape:

    square

Description

KTF Series diffusers are made of a external perforated panel inserted into an aluminium frame and a plenum connected with a connection on the top side. Steel deflectors can be placed inside allowing to modify the direction of the air on exit by adjusting their position.



Technical data

Sizes from 300x300 to 595x595
Air inlet diameter from 160 to 315mm
Panel diffuser steel frame with aluminum, galvanized sheet steel plenum
white paint finish RAL 9010
Installation height between 2.6 and 5.0 m
Internal baffles on request
