Mechanical lock HERCULAR®
for entry door1 pointbuilt-in

mechanical lock
mechanical lock
mechanical lock
mechanical lock
mechanical lock
mechanical lock
mechanical lock
Add to favorites
Compare this product


Characteristics

Mechanism
mechanical
Product applications
for entry door
Number of locking points
1 point
Installation
built-in
Other characteristics
high-security

Description

Application High Security deadbolt system for commercial and residential doors. Operation 90˚ key rotation throws the bolt 1" towards the frame, interlocking two hardened ball bearings with the strike to increase jimmying resistance. Options Standard faceplate Drive in (for beveled doors) Double cylinder Single cylinder Captive key deadbolt Materials Ring and cylinder: solid brass Bolt anti drilling ring: hardened steel Strike: steel Pins: nickel silver and stainless steel Standard finishes Nickel chrome matte; Nickel chrome; PVD Special finishes Antique brass; 10B Lifetime finishes US3; US26; US26D; US5A; US10B6 Additional features Suitable for two backsets, no need for different parts Supplied as standard with 1" (25 mm) throw Thumbturn tail adjustable to door width Thumbturn can be set horizontally or vertically in locked position Cylinder mechanism Mul-T-Lock's unique, high-precision pin tumbler system. Keys Reversible nickel silver key with plastic key head and colored insert. Also available in all nickel silver. Cylinder platforms Classic; Interactive®+ Cylinder options Keyed different Keyed alike Master keyed '3 IN 1' (changeable combination) Standards UL437; UL; Conforms to ANSI GRADE 1 Notes Spacers required for doors less than 38 mm width.
