ventilated facade cladding / terracotta / smooth / panel
TERRART® LARGE NBK Keramik

{{requestButtons}}

Characteristics

  • Material:

    terracotta

  • Finish:

    smooth

  • Configuration:

    panel

  • Color:

    beige

  • Other characteristics:

    for ventilated facades, large format

Description

provides large-format elements, which are individually manufactured based on the project specification. Ideal for projects where large-sized or oversized elements support wind load and structural and design aesthetic are a consideration.

Length: 100 mm – max. 3000 mm

Height: 150 mm – max. 800 mm

The height of the elements can be adjusted to the desired horizontal grid.

Thickness: 40-80 mm
For corners, we offer miter-cut elements or cut and bond corners. Alternatively, we provide specially designed corner plates with a maximum side length of approx. 250mm and a maximum height of 300mm.

Mass per unit area: approx. 65 kg/m²
