Reinforcement geogrid NIDAGREEN®

for ground stabilizationdrainagepatio

Nidagreen synthetic turf underlay Nidagreen® is used as a grid base for artificial turf in order to create outdoor layouts on ground surfaces, rooftops or balconies. Nidagreen® is an extruded polypropylene honeycomb panel, covered with a non-woven geotextile on both sides, specially designed to be placed between the artificial turf and the ground. The large size of the cellular panels makes them very quick to install, thereby reducing installation times. The honeycomb structure, is not only highly resistant to compression, but also has a significant water storage capacity in the event of very high rainfall. By using nidagreen®, the turf remains dry and very stable. Nidagreen® also contributes to absorbing shocks and is 100% recyclable. Advantages Extruded polypropylene honeycomb panels with 8 mm mesh Non-woven geotextile on both sides Artificial turf grid base Rainwater storage (95% of empty space), with subsequent natural infiltration Ideal for creating a landscaped area on the ground or on a rooftop, with no maintenance required Dimensions 2400 x 1200 mm 2 thicknesses: 21 mm and 28 mm 8 mm cell size
