Aluminum vapor barrier REFLECTATHERM PLUS

polypropylenepolyethylenereflective

With an R-Value of 0.79 m2K/W, Reflectatherm Plus is the industry leading reflective vapour barrier. It combines the highest thermal performance in its class with a high vapour resistance to prevent interstitial condensation.Suitable for use in walls, ceilings and floors on the warm side of the insulation. R-Value of 0.79 m2K/W Improved airtightness Creates service void Helps meets the requirements of the new ’Part L’ in England and Wales and ’Section 6’ in Scotland High vapour resistance Vapour Resistance of 750 MNs/g Detailed Description Vapour Control Layer to be used shall be Reflectatherm Plus supplied by The A Proctor Group, Blairgowrie. Reflectatherm Plus is a spun-bonded polypropylene nonwoven and foil laminate designed for use as a vapour control layer with the added benefit of enhance thermal performance when placed next to a cavity. Product performance specification as follows: Roll Size 1.5m x 50m, 2.7m or 3m x 100m Material Polypropylene Spunbond Nonwoven, Polyethylene and Foil laminate Certification Minimum required: BM Trada Q Mark available from The A Proctor Group. • Reflectatherm Plus BM Trada Q Mark Certificate Technical Properties • Mass per unit area: to be no less than 150g/m² • Water vapour resistance: to be no greater than Sd = 150m when tested to EN1931 • Reaction to Fire: to be no worse than Class E when tested to EN 11925-2 • Water Penetration: to be no less than Class W1, aged and unaged, when tested to EN 1928 • Tensile Strength: to be no less than MD 255N/50mm; CD 200N/50mm when tested to EN 12311-2 • Tear Resistance: to be no less than MD 164N; CD 157 N when tested to EN 12310-1
