Lighting control unit MASTERPIECE : SCREEN DRIVER

On Screen Text Labeling of all your programs Works with Masterpiece 216, 108, 96 and Replay Unit Stores two shows in non-volatile memory. Memory card backup An optional screen interface is available for the Masterpiece units. This interface is designed to help the lighting operator by replacing the program record sheets with an on screen display of the Channel Assignments, Scenes, Chases and Environments programmed. Additionally on-line Help Screens and Tutorial pages in many languages and a Bar Graph display also shows the channel levels in a graphical format. From early 1999 the screen driver will additionally display important DMX patching information when used with Masterpiece 216 and 108 units, this facility's can be upgraded to on existing units by means of software upgrades. Writing to the screen is done by switching the Masterpiece into Screen Text Mode. Once in Screen Text Mode, the keys are used to enter your text. Information is printed on each relevant key of the Masterpiece. Text for up two controllers (1 Master 1 Slave) can be typed into the Screen Driver. A Memory card is supplied to store the text you have typed.
