Pre-washing + first washing + enhanced washing + double rinsing.
2 speeds.
Fully stainless steel jacket.
Inlet and outlet splash guards are standard.
Stainless steel central rack feed system.
Process cycles are divided by rubber curtains.
Automatic cycle start.
Economy
Energy saving rinse supply switch.
Pressure controller in the rinse section to limit consumption.
Programmed automatic stops if there is no loading.
Stop and freezing of timer when the limit switch actuates.
Cleaning and maintenance
Wide pivoting door allowing access for cleaning or inspection purpose.
Detachable arms and dispersers for easier cleaning.
Specifications Sheet
Production
Production baskets/hour: 183 / 275
Production plates/hour: 3294 / 4950
Pre-wash
Temperature: 35 ºC - 45 ºC
Pre-wash basin capacity: 60 l
Pump: 1.2 Hp / 880 W
First wash
Temperature: 55 ºC - 65 ºC
1st wash tank capacity: 60 l
Pump: 1.2 Hp / 880 W
1st wash heating element : 6000 W
Boosted wash
Temperature: 55 ºC - 65 ºC
Wash tank capacity: 100 l
Pump: 3.5 Hp / 2600 W
Wash heating element: 9000 W
Pre-rinse
Temperature: 65 ºC - 75 ºC
Pre-rinse basin capacity: 15 l
Pump: 0.2 Hp / 0.15 W
Pre-rinse heating element: 6000 W
Rinse
Temperature: 80 ºC - 90 ºC
Water consumption: 480 l/h
Rinse heating element: 27000 W
Boiler capacity: 20 l
Drag
Drag motor power: 0.25 Hp / 180 W
Loading
Central module total power : 52790 W
External dimensions (WxDxH)
Width: 3500 mm
Depth: 829 mm
Height: 1520 mm
Net weight: 540 Kg
Water Intake: 3/4 "
Drain diameter: 1 1/2 "
Noise level (1m.): 71 dB(A)
Please note: +3kW rinse heating element in models equipped with steam condenser.
Crated dimensions
4370 x 980 x 2000 mm
