Designed for commercial /professional installations.
70v/100v or 8-ohm bypass switch.
Selectable transformer to fine-tune listening output.
3/4" (19mm) pivoting cloth dome
6 1/2" (165mm) polypropylene cone with a rubber surround
65Hz - 20kHz -10dB
120º conical
140 watts maximum program power; 70 watts continuous pink noise
5.9 averaged from 500Hz - 4kHz
4.6 averaged from 500Hz - 4kHz
Primary voltage: 70V /100V Primary taps (70V): 7.5W, 15W, 30W, 60W Primary taps (100V): 15W, 30W, 60W 8-ohm bypass
89dB SPL (2.83V/1 meter)
Deep-drawn steel back can
ABS (meets UL94V-0 fire rating)
Locking removable quick-connect with 2 input terminals and 2 loop through terminals
UL-1480, CE
7 1/2" (191mm)
Paintable weather resistant aluminum
9 3/4" (248mm)
8 5/32" (207mm)
19 lbs (8.61kg) pair
C-support plate, 2 international compatible tile support rails, cutout template, paint plug, removable quick-connect wire terminator
