Hanging light fixture LOGICO SYSTEM
surface-mountedLEDlinear

hanging light fixture
hanging light fixture
hanging light fixture
hanging light fixture
hanging light fixture
hanging light fixture
Add to favorites
Compare this product


Characteristics

Type
hanging, surface-mounted
Light source
LED
Shape
linear
Protection class
IP20
Application
commercial
Material
aluminum, extruded aluminum
Color
white
Style
contemporary
Dimmable
dimmable
Number of lights
single
Other characteristics
modular lighting system, DALI
Height

100 mm
(4 in)

Length

562 mm, 1,122 mm, 1,682 mm
(22 in, 44 in, 66 in)

Width

60 mm
(2 in)

Power

Min.: 8 W

Max.: 192 W

Color temperature

3,000 K, 4,000 K

Color rendering index (CRI)

80 unit, 90 unit

Description

CONCEPT Linear LED fixture for ceiling mounted or suspension system installation. MATERIALS Painted extruded aluminium body, available in four different lengths. Rapid fixing system to fix the light unit to the housing using magnets complete with an anti-fall safety cable. OPTIC LED Engine composed of linear Ra 84 LED boards. White Tunable version available on request. Available with direct or direct/indirect emission with three different light effects: Diffused light: opal screen - Highly reflective brushed aluminium reflector and opaline polycarbonate screen. UGR<19 Controlled light - Optical system composed of a highly reflective brushed aluminium reflector and a transparent polycarbonate screen coupled with a micro prismatic plate and a spreader lens. 600mm module not available. Wall washer - Optical system composed of a highly reflective polished aluminium reflector, a PMMA cylindrical lens, holographic filter and transparent polycarbonate cover. 600mm module not available. INSTALLATION For linear configurations complete with a special connector to attach to the power supply. For other configurations accessorise with special connectors to X, T and L only available with the diffused light version with an opal screen. To be completed with mounting systems and end caps. POWER SUPPLY Integrated electronic power supply or DALI. Complete with electrical cables to guarantee feeding continuity (max 2kW). Emergency Pack available on request. COLOUR AND FINISH DEEP BLACK GREY PLASTER WHITE SIZE AxBxH=1139x1139x100mm AxBxH=1139x600x100mm AxBxH=600x600x100mm L=1122mm L=1682mm L=3364mm L=562mm COLOUR TEMPERATURE 3000K 4000K POWER (SOURCE) 18w - 120w CRI 84
