recessed downlight / LED / round / cast aluminum
DIAMO ZUMTOBEL

{{requestButtons}}

Characteristics

  • Type:

    recessed

  • Light source:

    LED

  • Shape:

    round

  • Material:

    cast aluminum

  • Market:

    for hotels

  • Other characteristics:

    dimmable, wall washer

  • Protection class:

    IP20

Description

Miniaturised LED downlight for high-performance accent lighting
Compact design with minimalist look
Maximum sparkle thanks to specially designed reflectors made of silver-anodised, highest-grade aluminium
Precise light distribution with no stray light and excellent glare control (flood (FL), wideflood (WFL), very wideflood (VFL), wallwasher (WW))
Housing includes integral passive cooling
Housing made of die-cast aluminium
Colour: White
Complete model consists of luminaire and ballast unit (switchable) or (LDO: dimmable Dali only/switchDim)
50000 h service life at 80 % luminous flux
Colour temperature: 2700 K (LED927: warm white), 3000 K (LED930: warm white), 4000 K (LED940: intermediate white)
Colour rendering index: Ra > 90
Luminaire luminous flux: 800–1300 lm (14 W (LDO)/15 W), 1200–1900 lm (25 W)
Mains voltage: 220–240 V / 0/50/60 Hz
Luminaire pre-wired using halogen-free leads
2-pole connection terminal with plug connection, 5-pole ( dimmable Dali only)
Installation: by means of concealed screw-fixing, ceiling thickness 1–25 mm
Please go to the main product name in the ONLINE catalog to find the latest power consumption figures based on continuous improvements in efficiency
