Highly flexible recessed ceiling luminaire for classic cardanic lighting
LED module for precise, diverse accent lighting
Asymmetric "lightgroove" design element ensures perfect integration into the ceiling and marginal gap dimensions
Lamp unit made of diecast aluminium, coated white
Black or matt-silver versions can be ordered
Black polycarbonate front ring provides excellent glare control
Passive cooling achieved by innovative thermal design
Dimmable Dali only version: illuminance level has 1–100 % dimming adjustment
Mains voltage: 230 V / 50/60 Hz
Specular reflector designed to be interchangeable
Luminaire pre-wired using halogen-free leads
Please go to the main product name in the ONLINE catalog to find the latest power consumption figures based on continuous improvements in efficiency
FW/BKY versions: with colour temperature specifically matched to requirements of meat and bakery products
Version T30 (True Gamut Rendering): enables lively colour effects particularly with white and coloured apparel
Mounted in CARDAN evolution M single, double or triple installation frame/ring, to be ordered separately
Sparkling accentuation from precision reflectors delivers exact beam pattern ranging from spot to wideflood
Specular reflector of aluminised PC, highly specular, iridescence-free
Multifunctional lamp unit rotatable (360°) and tiltable (+30°)
If the cover glass (IP54) is used, the luminaire can no longer be tilted
Light module consists of luminaire and SWI ballast unit (switchable) or LDO (dimmable Dali only/switchDim), and wireless connection via app with Bluetooth® 4.x - basicDim Wireless
