Screw piles
{{#each product.specData:i}}
{{name}}: {{value}}
{{#i!=(product.specData.length-1)}}
{{/end}}
{{/each}}
{{{product.idpText}}}
{{#each product.specData:i}}
{{name}}: {{value}}
{{#i!=(product.specData.length-1)}}
{{/end}}
{{/each}}
{{{product.idpText}}}

Nominal length 1600 mm Pipe - Ø 139,7 mm Weight 17 kg Item no. 26160 Set-up diameter 100 mm 90 mm 80 mm 76 mm Set-up depth 730 mm 775 mm 810 mm 810 mm Steel, galvanized according to DIN EN ISO 1461
Krinner Schraubfundamente

Nominal length 1300 mm Pipe - Ø 139,7 mm Weight 11,0 kg Item no. 25502 Set-up diameter 100 mm 90 mm 80 mm 76 mm Set-up depth 565 mm 630 mm 650 mm 650 mm Steel, galvanized according to DIN EN ISO 1461; available starting June 2011
Krinner Schraubfundamente

Nominal length 1000 mm Pipe - Ø 88,9 mm Weight 5,50 kg Item no. 24100 Set-up diameter 60 mm Set-up depth 270 mm Stahl, feuerverzinkt nach DIN EN ISO 1461
Krinner Schraubfundamente

Nominal length 800 mm Pipe - Ø 88,9 mm Weight 4,30 kg Item no. 24080 Set-up diameter 60 mm Set-up depth 270 mm Steel, galvanized according to DIN EN ISO 1461
Krinner Schraubfundamente

Nominal length 550 mm Pipe - Ø 88,9 mm Weight 3,5 kg Item no. 24055 Set-up diameter 60 mm Set-up depth 270 mm Steel, galvanized according to DIN EN ISO 1461
Krinner Schraubfundamente

Nominal length 1600 mm Pipe - Ø 139,7 mm Weight 17 kg Item no. 25484 Steel, galvanized according to DIN EN ISO 1461
Krinner Schraubfundamente

Nominal length 2100 mm Pipe - Ø 139,7 mm Weight 24 kg Item no. 25490 Set-up diameter 75 mm 80 mm 90 mm 100 mm Set-up depth 812 mm 799 mm 772 mm 746 mm Steel, galvanized according to DIN EN ISO 1461
Krinner Schraubfundamente

Nominal length 1600 mm Pipe - Ø 139,7 mm Weight 20 kg Item no. 25489 Steel, galvanized according to DIN EN ISO 1461
Krinner Schraubfundamente

Nominal length 1600 mm Pipe - Ø 76,1 mm Weight 12,5 kg Item no. 25478 Steel, galvanized according to DIN EN ISO 1461
Krinner Schraubfundamente

F 76x1300-R Nominal length 1200 mm Pipe - Ø 76,1 mm Weight 9 kg Item no. 25477 Steel, galvanized according to DIN EN ISO 1461
Krinner Schraubfundamente

... flanges cast continuously around the pile shaft. 6. The completed screw-shaped Atlas pile – If necessary, reinforcement cages are placed manually over the upper part of the pile, ...
FRANKI FOUNDATIONS BELGIUM

The Omega screw pile is a vibration-free pile with lateral soil displacement. Soil displacement occurs during both the screwing-in (2.) and the screwing-out (4.) installation sequences ...
FRANKI FOUNDATIONS BELGIUM

The Omega pile with grout injection is a pile designed as a vibration-free screw pile with lateral soil displacement. The penetration into resistant layers of soil such ...
FRANKI FOUNDATIONS BELGIUM

The screwed tube pile is a full-displacement pile with permanent steel casing and screw tip. The pile is formed vibration-free, by screwing steel tubes into the soil ...
FRANKI FOUNDATIONS BELGIUM

... down under and around the pile base and along the pile shaft. 3. Welding of the next tubed element and injection of the grout around the pile base and along the pile ...
FRANKI FOUNDATIONS BELGIUM

The "Pressurized Concrete Screw Lambda" or PCS Lambda (λ) screw pile is a screw pile with a large stem implying a partial displacement of soil during ...
FRANKI FOUNDATIONS BELGIUM

Utilising the Martello Technique, large diameter piles (750/900/1050mm) are able to be constructed to depths of 40.0m to form fully reinforced piles of up to 8.0mN in restricted access and low headroom ...
FRANKI FOUNDATIONS BELGIUM

... concrete, and clean up the mess makes Techno Metal Post the only way to begin a deck project.” SCREW PILES AND HELICAL ANCHORS ARE UNIQUE AMONG MOST OTHER TYPES OF FOUNDATIONS OR ANCHORING SYSTEMS. ...
Techno Pieux inc.

... principle of cathodic protection to ensure that even helical piles installed in corrosive soils are protected for the long term. Hot-dip galvanizing provides long-term protection for foundation piles. Techno ...
Techno Pieux inc.
