Construction characteristics
Illuminotechnical characteristics
Downward bilateral distribution.
Lifetime (L75/B10): 30000 h. (tq+25°C)
Lifetime (L70/B10): 50000 h. (tq+25°C)
Photobiological safety RG0, risk exempt, in compliance with IEC 62471, IEC/TR 62778.
Mechanical characteristics
Self-extinguishing V2 polycarbonate housing, injection moulded, RAL 7035 grey.
Flow recuperator in specular aluminium with superficial titanium-magnesium treatment, non-iridescent.
Transparent PMMA diffuser, injection moulded, with smooth outer surface and differentiated prismatic inner surface.
Sealing gaskets between housing and diffuser in ecological anti-aging EPDM.
Diffuser safety seal with 4 latches attaching it to the housing, in stainless steel.
Electrical characteristics
In compliance with EN 60598-1.
Double insulated cables.
Line entry at rear through rubber seal or at side after drilling.
Class II.
Source characteristics
LED modules.
Color initial tolerance (MacAdam): SDCM 4.
On request
LED sources with different colour temperatures
different powers
Applications
Wall mounting, particularly suitable for outdoor lighting of civil and industrial buildings, porticos, underpasses and walkways.
Downwards bilateral controlled distribution allows to optimise the perimeter lighting uniformity of buildings.
Control of light pollution, in accordance with the legislative requirements in force.
