Recessed light fixture LINARGO BL

hangingsurface-mountedLED

Short description
A minimalist, highly homogeneous linear LED luminaire. LED Linargo is available as a surface-mounted module system that can be linked to form a continuous lighting band, and as a pendant with suspension cable. Suited for corridors, offices and counters in architectural interiors.

Features

• Designed for acoustical ceilings; suitable for hotels, offices, showrooms, laboratories and production areas
• Uniform light distribution without dark zones, even when multiple modules are joined
• Direct and/or indirect lighting options
• Optional tunable white (variable colour temperature)
• Light outputs dimmable and controllable (DMX)
• Acoustic panel available in a technical version for hot and humid environments
• Fully recyclable construction
• Glare control via satinised PMMA diffuser
• Clamps for fast wiring between LED modules
• Compatible with emergency lighting systems according to EN 50172

Technical details (overview)
LED Linargo BL 300
Dimensions [W x H]: 42 x 200/300/600 mm; Standard lengths: 1,130 / 1,270 / 1,410 / 1,550 / 1,690 mm; Special lengths on request; Max length: 2,390 mm; LED grid: 140 mm, row installation possible
Power consumption: Max. 38 W depending on factory preset
Luminous efficacy: approx. 144 lm/W | light output variants: 840 or 830
Beam angle: 120° diffuse PMMA cover
Service life: LED + driver: 50,000 h at 70% of mean luminous flux
Colour temperature: 3,000 K or 4,000 K (white)
CRI: > 85; narrow colour tolerance MacAdam Step 3
Standard/Performance: UGR < 19; L65 < 1,500 cd/m² (EN 12464-1:2011)
Control interfaces: DALI DEVICE Type 6, DSI, switch DIM with memory, corridorFUNCTION
IP rating: IP40
Housing: aluminium, RAL powder-coated; satinised PMMA diffuser
Mounting: pendant (stainless steel cable 2.0 m + translucent supply line) or recessed (spring clips)
Driver: Tridonic LCA 75W or LCA 100W (type by luminaire length) with overload, overtemperature and short-circuit protection
Supply line: 5 x 1.5 mm translucent with 5-pole Wieland connector

Characteristics / technical specifications

• Model: LED Linargo BL 300
• Dimensions: W x H 42 x 200/300/600 mm; standard lengths 1,130–1,690 mm; max length 2,390 mm
• LED grid: 140 mm; row installation possible
• Power consumption: up to 38 W (factory preset dependent)
• Luminous efficacy: approx. 144 lm/W
• Light output options: 840 or 830
• Beam angle / cover: 120° diffuse PMMA
• Service life: 50,000 h (LED + driver at 70% output)
• Colour temperatures: 3,000 K or 4,000 K
• CRI: > 85, MacAdam Step 3
• UGR: < 19; L65 < 1,500 cd/m² (EN 12464-1:2011)
• Control: DALI DT6, DSI, DIM switch, corridorFUNCTION; DMX dimmable option
• IP rating: IP40
• Housing: powder-coated aluminium; satinised PMMA for glare suppression
• Mounting options: pendant (2.0 m stainless steel cable + translucent supply line) or recessed (spring clips)
• Driver: Tridonic LCA 75W/100W with overload, overtemp and short-circuit protection
• Supply: 5 x 1.5 mm translucent cable with 5-pole Wieland plug
• Additional: tunable white, acoustic technical version, clamps for quick wiring, fully recyclable, EN 50172 compatible
