Wall-mounted acoustic panel ORFE

fabricwoolglass

The fabric covered panel used for improving the ambient acoustics can be used in all wall and ceiling details. The biggest advantage in application detail is that the product is easily removable when it is mounted. ORFE acoustic wall panels are applied to wall and ceiling surfaces with two different clips without using adhesive. Z clips or hooks can be mounted with clips by application surface and material back surface. In addition to sound absorption, fabric coated panels can be used in a decorative appearance and can easily be applied on concrete or gypsum board surfaces. A soundproofed ORFE acoustic panel with a high sound absorption coefficient can be used in sound recording environments where sound and acoustic reflections are most critical. In offices, large-scale offices and open offices with high number of employees, acoustic panels can be preferred on wall and ceiling surfaces in environments with more than one employee at the same time. Product Description Core Material : 95 kg/m3 density acoustic glass wool. Size : 600 × 600 mm, 600 × 1200 mm, 600 × 1800 mm, 600 × 2400 mm, 600 × 2700 mm,600 × 3000 mm, 1200 × 1200 mm, 1200 × 1800 mm, 1200 × 2400 mm, 1200 × 2700 mm, 1200 x 3000 mm Thickness : 20-40 mm Edge Detail : Straight Edge on Aluminum Frame. Acoustic Performance : NRC value 0.95 - 1.00 Yangın Dayanımı : Class A2 s1 d0 acoording to UNE-ON 13501-1:2007 Application : Hook And Z Clips
