Smartphone wireless charger LS 990

integrated

Overview
Wireless magnetic charging integrated into switch and socket frames. The JUNG Magnetic Charger supports the Qi2 standard and delivers up to 15 W of wireless power. Designed to fit LS 990, A 550 and A VIVA frame systems, it enables tidy installations without visible cables — suitable for residential, hotel and office applications.

Design & Integration
Conceived to match the proportions, colours and mounting of JUNG LS and A ranges, the charging surface is available in finishes that align with LS 990 and A series frames. The unit can be installed as a single‑gang element or horizontally across multiple frames to maintain a consistent interior design.

Technology & Operation
The Magnetic Charger complies with the Qi2 standard for cross‑manufacturer interoperability. Integrated magnets provide defined alignment between charger and device for stable magnetic holding and efficient energy transfer. Charging is supported with or without protective cases when the device/case is Qi2 or MagSafe compatible.

System composition
The product is modular, consisting of cover, frame and charging insert, and is compatible with LS and A frame systems to allow discreet integration into existing switch and socket setups.

Key functional highlights

• Qi2 standard compatibility for cross‑manufacturer interoperability
• Integrated magnets for precise alignment and stable magnetic hold
• Wireless output up to 15 W
• Works with compatible protective cases (Qi2 or MagSafe)
• Variants matching LS 990, A 550 and A VIVA designs
• Installable as single‑gang or horizontally in multiple frames

Related charging & USB options
JUNG offers complementary wired charging solutions that integrate into the same frame systems, including SCHUKO® sockets with integrated USB A/C ports (typical combined output ~15 W), variants with JUNG Quick Charge® (18 W) and USB Power Delivery chargers up to 60 W (PD 3.0, Quick Charge 4+, PPS) for fast charging of laptops and mobile devices.

Technical specifications

• Standard: Qi2 (manufacturer‑agnostic compatibility)
• Maximum wireless charging output: up to 15 W
• Magnetic alignment: integrated magnets for defined positioning and stable holding force
• Compatibility: Qi2 and MagSafe compatible devices (including via compatible protective cases)
• Design integration: fits JUNG LS (LS 990) and A (A 550, A VIVA) ranges; available in matching finishes
• Modular construction: cover, frame, charging insert
• Installation options: single‑gang and horizontal multiple‑frame installation
• Related wired options: USB chargers with PD up to 60 W; SCHUKO® sockets with integrated USB A/C (typ. 15 W combined) and Quick Charge variants (18 W)
