Aluminum window STAR75

with hidden openingtriple-glazed1 leaf

Overview
Clean design and high-performance thermal insulation. The Star75 window system integrates modern technologies into a single solution. Its slim appearance combined with effective insulation makes it suitable for low-energy houses, both new builds and renovations. Star75 is available in four insulation levels: Star75 / Star75 i / Star75 i+ / Star75 Hi, offering a thermal performance option for each building requirement.

Key advantages

• Slim, contemporary profile
• High thermal insulation values
• Four insulation levels available
• Suitable for energy-efficient homes (including Q‑ZEN)
• Available in Modern and Luxus designs
• Also available with a concealed sash so the opening is not visible from the outside

Characteristics (table)
Frame depth: 75 mm / 90 mm (Luxus)
Sash depth: 84 mm / 94 mm (Luxus)
Fixed glazing thickness range: 12 mm - 61 mm
Sash glazing thickness range: 21 mm - 69 mm (or 18 mm - 58 mm for OC)
Uw example: 0.94 W/m²K (dimensions: 1230 mm x 1480 mm; UG: 0.6 W/m²K & PSI: 0.036 W/mK) for profiles RS010-RS020
Uf thermal transmittance Star75: 1.5 W/m²K
Uf Star75 i: 1.2 W/m²K
Uf Star75 i+: 0.97 W/m²K
Uf Star75 Hi: 0.97 W/m²K
Uf Star Luxus: 0.97 W/m²K
Air tightness: Class 4 (NBN EN 12207)
Water tightness: E1200A (NBN EN 12208)
Wind resistance: C5 (NBN EN 12210)
Impact resistance: Class 4
Burglary resistance: RC2 / RC3 (flat door)
Operating forces: Class 1 (NBN EN 13115)
Acoustic performance: up to 47.1 dB (-1;-4)
Fire resistance: EW30-EI30 (not for VV and Luxus)
ATG certified: Yes
KOMO certified: Yes

Technical specifications

• Brand: Aliplast
• Available models: Star75, Star75 i, Star75 i+, Star75 Hi, Star75 Luxus
• Frame depth: 75 mm / 90 mm (Luxus)
• Sash depth: 84 mm / 94 mm (Luxus)
• Fixed glazing thickness accepted: 12 mm - 61 mm
• Sash glazing thickness accepted: 21 mm - 69 mm (or 18 mm - 58 mm for OC)
• Uf values: Star75 = 1.5 W/m²K; Star75 i = 1.2 W/m²K; Star75 i+ = 0.97 W/m²K; Star75 Hi = 0.97 W/m²K; Luxus = 0.97 W/m²K
• Uw example: 0.94 W/m²K (for 1230 x 1480 mm; UG 0.6 W/m²K; PSI 0.036 W/mK) for profiles RS010-RS020
• Air tightness: Class 4 (NBN EN 12207)
• Water tightness: E1200A (NBN EN 12208)
• Wind resistance: C5 (NBN EN 12210)
• Impact resistance: Class 4
• Burglary resistance: RC2 / RC3 (for flat door)
• Operating forces: Class 1 (NBN EN 13115)
• Acoustic performance: up to 47.1 dB
• Fire resistance: EW30-EI30 (except VV and Luxus)
• Certifications: ATG (yes), KOMO (yes)
