Overview
Custom aluminum and steel hotel pergola systems for resort pools, rooftop bars, restaurant terraces and guest lounges. alux supplies architects, hospitality procurement teams, contractors and resort developers with project customization, export packing and B2B delivery.

Key advantages

• Factory direct: no middleman on large project orders, enabling clear specification control.
• Repeatable units: uniform quality across every bay and terrace.
• Compliance documentation: structural, wind, fire, drainage and coating test reports for project sign‑off.
• Project support: drawings, packing and staged delivery scheduling for multi‑phase fit‑outs.

Custom system
Configure the pergola to property needs: select structure type, material, roof system, side enclosure, lighting and finish to match brand identity, guest flow, climate and seasonal revenue strategies.

Custom Elements / Options

• Structure: modular repeatable units (freestanding, wall‑mounted, cabana or linked runs).
• Material: aluminum for coastal and rooftop use; steel for wide spans and heavy‑duty venues.
• Roof System: motorized louvered roofs (0°–100° rotation), fixed or louvered options.
• Side Enclosure: glass sliding/folding walls, Zip Screens, curtains or louver walls for wind and weather control.
• Lighting: integrated LED strips in frames and louvers for evening service and ambience.
• Finish: custom RAL brand colors; ZAM coated steel with 80 μm powder coat; UV‑stable coatings for aluminum.

Material selection (comparison)

• Steel pergola — Best for: wide venue spans, event spaces and inland properties. Advantages: high strength for long spans; cost‑effective at volume; ZAM + 80 μm powder coat; example salt‑spray verification: 168 h.
• Aluminum pergola — Best for: beachfront and poolside resorts, rooftop bars and low‑maintenance portfolios. Advantages: corrosion resistant, lightweight for rooftop work; easier standardization across chains.

Applications

• Resort pools & cabanas — rows of louvered pergolas shading pool decks.
• Restaurant terraces — covered dining that trades in variable weather.
• Rooftop bars & lounges — wind‑aware structures for exposed roofs.
• Villa & suite terraces — private shaded terraces for premium units.
• Lodge & alpine terraces — rated‑load structures for snow‑region resorts.
• Event & spa spaces — enclosable structures for functions and gardens.

Recommended hotel configurations

• Resort pool program: aluminum cabanas + louvered roofs + repeatable bays.
• Restaurant terrace: motorized louvers + Zip Screen + integrated LED.
• Rooftop bar: wind‑conscious aluminum structure + glass screens.
• Four‑season dining: glass sliding walls + louvered roof + heating‑ready layouts.
• Snow‑region lodge: reinforced structure + roof load ratings (series from ~50 to 120 kg/m²).
• Multi‑property rollout: standardized spec + brand colors + staged delivery and packing.

Compliance & testing
Documentation prepared for architect and consultant sign‑off includes structural and wind load tests, waterproofing and drainage verification, coating salt‑spray testing, and certifications (CE, UKCA, TÜV, EMC/LVD where required). Quality controls: IQC, IPQC, FQC and OQC; motors and roof systems specified for commercial‑duty cycling.

Factory & production notes
In‑house product development supports cutting, drilling, assembly, coating and selected system testing. Typical factory workflows include KD export packing, labeled hardware kits and containerized packing to support staged site delivery.

Process overview

• Requirement — confirm property type, areas, unit count, schedule, material and accessory needs.
• Recommendation — advise steel or aluminum, louvered or motorized configuration.
• Drawing — review dimensions, structure, color, roof and enclosure options.
• Production — cutting, assembly, coating and system testing.
• QC & packing — inspect dimensions, coating, louver movement, motors and LEDs; KD packing and labeled kits.
• Shipment & support — container loading support, export documents, installation guides and after‑sales spare parts.

Technical specifications

• Modular repeatable unit concept: one profile family repeated across decks and terraces.
• Roof louver rotation: 0° to 100° for light, airflow and waterproof closure.
• Motor duty: rated for daily commercial cycling (hospitality duty).
• Steel protection: ZAM coated steel + 80 μm powder coat; example salt‑spray: 168 h.
• Aluminum finish: UV‑stable coatings for long‑term color hold.
• Rated roof loads (snow options): series from approx. 50 to 120 kg/m².
• Water management: integrated frame drainage and post drainage.
• Lighting: integrated LED strips within frames and louvers; circuits coordinated with roof system.
• Packing: knock‑down export packing, labeled kits, carton numbering for staged delivery.
• Factory capacity: multi‑thousand sets/month indicative depending on model and scope.
