Water/water heat pump WBHP-2

residentialoutdoorsplit

• High efficiency hot water unit • Satisfies the residents’ daily demand for hot water in big house (bath, shower, laundry, washing, underfloor heating, etc.) • R410A, probably the most preferred refrigerant at the present time, easy to maintain and commonly used • Safe and environment friendly • Energy-saving, uses renewable energy source (outside air), and reduces electricity heating costs by 50-80% • the cost even more economical, if solar heating is added • Reduces carbon emissions by offsetting electricity usage • Simple to install • Works all day and not affected by the severe weather • Compatible with connection to a solar thermal collector Rated power input (kW) 1.59 COP 4.40 Hot water temperature range 20～55℃ (Adjustable) Applicable ambient temperature -7～43℃ Rated hot water capacity (L/h) 150 Circulating water flow (m­³/h) 1.20 Power supply 1Φ/220~240V/50Hz Compressor type Rotary Nominal current (A) 8.50 Max current (A) 12.75 Refrigerant R410A Water resistance <50kPa Water pipe interface DN20 Box dimensions (mm) 1110×375×950
